Wear resistant hexagon alumina ceramic lining tile hex tablet

Product Overview

Description

Alumina ceramic hexagon tile hex tablet



Cylinder Parameter



	92 Series	95 Series
Item
Al2O3 Content %	≥92	≥95
Rate of Water Absorption %	≤0.01	≤0.01
Specific Gravity g/cm3	≥3.60	≥3.65
HardnessMohs Scale	9	9
Anti-Compression Strength MPa	≥2000	≥2250
Application: Oil, mining, steel and power industry.



effectively prolong the service life of equipment and considered to be the best choice of anti-wearing and anti-corrosion material;

Wear resistance of ceramic is 266 times than that of special manganese, 171.5 times to high chrome cast iron;

Hardness is much higher than that of wear-resistant steel and stainless steel.



Size(mm)	Length (mm)	Width (mm)	Thickness (mm)	Remark
10x10 Lining Mat	10	10	4~10	rectangle,support with paper tape.
17.5x17.5 Lining Mat	17.5	17.5	4~10	rectangle,support with paper tape.
20x20 Lining Mat	20	20	4~10	rectangle,support with paper tape.
11.5x11.5 Lining Mat	11.5	11.5	4~10	hexagon,support with paper or fabric tape,with or without 1mm separate









service of both ODM and OEM is available to all interested parties.  most welcome to visit our advanced manufacturing facilities in Lianyungang, a picturesque port city to the north of Shanghai.
