Aluminum electroplating Carbon fiber fabric

Product Overview

Description

We can supply metal plating 3k carbon  cloth for auto parts

FAW:200gsm ,

weave:plain,

width:100cm~150cm

roll length:100m

thickness: 0.27mm



The application are for
1.sports goods application
2.shoes parts application
3.composite application
4.car parts application

If you feel interested in our products,please give us your E-mail address.
Because Alibaba will not open your E-mail unless you write down your e-mail address with your reply...
We will sent you sample  and detail informations.

Thanks

Oliver Chou



JINSOR Set weave finish carbon fiber fabrics specifications
Advantages: Set weave finish can fix the carbon fiber yarn and will not disorder the fabric even pulled by hands.

Code No (pictures&Application) weave pattern Thickness (mm) width(cm) weight(g/m2) counts/inch fiber photos warp weft warp weft JSC 0151P & Application Set weave Plain 0.16 50~200 136 17 17 1.5K 1.5K JSC 0151T & Application Set weave Twill 0.16 50~200 136 17 17 1.5K 1.5K JSC 0152P & Application Set weave Plain 0.17 50~200 162 20 20 1.5K 1.5K JSC 0153P & Application Set weave Plain 0.15 50~200 100 12.5 12.5 1.5K 1.5K JSC 0154P & Application Set weave Plain 0.16 50~200 145 18 18 1.5K 1.5K JSC 0156P & Application Set weave Plain 0.14 50~200 96 12 12 1.5K 1.5K JSC 0301P & Application Set weave Plain 0.3 50~200 200 12.5 12.5 3K 3K JSC 0302P & Application Set weave Plain 0.35 50~200 225 15 13 3K 3K JSC 0303P & Application Set weave Plain 0.35 50~200 240 15 15 3K 3K JSC 0304P & Application Set weave Plain 0.25 50~200 160 10 10 3K 3K JSC 0305P & Application Set weave Plain 0.25 50~200 164 12.5 8 3K 3K JSC 0306P & Application Set weave Plain 0.28 50~200 273 17 17 3K 3K JSC 0311T & Application Set weave Twill 2x2 0.3 50~200 200 12.5 12.5 3K 3K JSC 0312T & Application Set weave Twill 1x3 0.3 50~200 200 12.5 12.5 3K 3K JSC 0313T & Application Set weave Twill 2x2 0.35 50~200 240 15 15 3K 3K JSC 0313T3 & Application Set weave Twill 3x3 0.35 50~200 240 15 15 3K 3K JSC 0314T & Application Set weave Twill 2x2 0.25 50~200 160 10 10 3K 3K JSC 0316T4 & Application Set weave Twill 4x4 0.38 50~200 272 17 17 3K 3K JSC 0321S & Application Set weave Satin 8H 0.42 50~200 368 23 23 3K 3K JSC 0322S & Application Set weave Satin 5H 0.4 50~200 280 17.8 17.8 3K 3K JSC 0601P & Application Set weave Plain 0.5 50~200 320 10 10 6K 6K JSC 0604P & Application Set weave Plain 0.4 50~200 290 9 9 6K 6K JSC 0611T & Application Set weave Twill 2x2 0.5 50~200 320 10 10 6K 6K JSC 0612T & Application Set weave Twill 2x2 0.55 50~200 400 12.5 12.5 6K 6K JSC 0613T & Application Set weave Twill 2x2 0.35 50~200 205 6 7 6K 6K JSC 0621S & Application Set weave Satin 5H 0.55 50~200 380 12 12 6K 6K JSC 1201P & Application Set weave Plain 0.65 50~200 510 8 8 12K 12K JSC 1202P & Application Set weave Plain 0.65 50~200 576 8 10 12K 12K JSC 1204P & Application Set weave Plain 0.6 50~200 378 6 6 12K 12K JSC 1211T & Application Set weave Twill 2x2 0.65 50~200 510 8 8 12K 12K JSC 1212T & Application Set weave Twill 2x2 0.65 50~200 576 8 10 12K 12K JSC 1213T & Application Set weave Twill 2x2 0.7 50~200 650 10.5 10.5 12K 12K JSC 1214T & Application Set weave Twill 2x2 0.6 50~200 378 6 6 12K 12K JSC 1215T & Application Set weave Twill 2x2 0.6 50~200 630 10 10 12K 12K JSC 2401P & Application Set weave Plain 0.85 50~200 770 5 7 24K 24K SCP100 & Application Set weave Plain 0.13 100 100 1.6 1.6 16mm spread 12K 16mm spread 12K Carbon fiber fabrics application are as follows 1. carbon sporting goods: golf shaft,tennis racket,ski board,snow board,surfboard,fishing rod... 2. carbon car parts: hood,front fender,steering wheel,gear shift,mirror cover,trunk cover. 3. carbon shoes parts:shoes sole,shoes trim... 4. carbon boat parts:mast,kayak,loom,loom blade,boat shell. 5. carbon electronic parts:speaker cone,mobile phone shell,carbon laptope shell.
