Product Overview

Description











CHARACTERISTICS





Key Specification:


Water is rapidly heated by the heat pipe


There is no water in the vacuum tube, so the tube will not break in winter


The small size of the collector allows for versatile architectonic integration


Collector can be combines with existing pipeline


The collector can operate even in case of a broken tube. A single tube can if necessary be exchanged without interruption of the heating cycle.





PARAMETER TABLE-1

































































Type

Area


(m2)



Volume of the


fluid(L)



Vacuum tube


Qty(pcs)



Length/Width/


Height(mm)



Gross


wet(kg)



20GP/40GP/40HC


loading Qty(sets)


JDL-PM10-58/1,81.30.77102020x995x155390.18
JDL-PM15-58/1.81.91.15152020x1410x155530.24
JDL-PM20-58/1.82.61.54202020x1825x155690.29
JDL-PM25-58/1.83.31.92252020x2240x155830.36
JDL-PM30-58/1.83.92.3302020x2655x1551090.43
Vacuum tube size:58x1800




REMARK








Outer tank: aluminum alloy 2.0mm


Frame if made of aluminum alloy.


Manifold connection(inch):1/2 3/4


Test pressure(pa):1MPa


Operating fluid ppressure(pa):0.6MPa


Max. service temperature:95


Max. stagnation temperature:242


Distance from tube to tube:75


Flow range recommendation:50-150l/m2h


Insulation thickness(mm):40


Min. collector angle(degree):15


Max. collector angle(degree):75










Click Here To Get Quick Quotation


1.Non-pressurized s2.Non-pressurized s










-1._02






FAQ


Q:What is your delivery time?
A: 15 working days after receipt of signed PI and down payment
Q:Which payment methods can you support?
BY T/T: 30% as down payment, balance to be paid against the copy of Bill of Lading.
Q: Are you trading company or manufacturer ?
A: We are factory.


Q:What is your package ways?
A:Generally, standard products with standard package.  Extra charge may be required for other custom requirements such as package logo printing
