MG series electric accelerator

Product Overview

Description









                   1.  Hall electric Accelerator











               2.  MG electric  Accelerator





                               3.  New Electronic throttle





1.Electric Accelerator

2.pedal

3. Electronic throttle



MG series pedals are applied mostly in electric hunting buggies, golf cars, electric antique vehicles and many other vehicles.



 FEATURES



 Water and Vibration proofed



 High stability, low draft with temperature.



 No rub design, long life span.



 Optimized output curve, makes driving comfortable.



 Specifications



Input Voltage range:         DC24V-80V or DC 60V- 44V



Output Voltage range:        DC 0V-5V



Environmental Enclosure:     IP68



Shock and Vibration:         SAEJ1378







Safety-North America:       UL2202/UL1564 2nd Edition



Emissions- North America:    FCC Part 15/ICES 003 Class A



Immunity-Europe:           EN61000-4-2/3/5/6/11



Operating Temperature:       -20°C-50°C



  Wires



Red:Power+                Black:Power–



Blue:Signal                 Yellow:Switch



Note:It will be bad when disconnect the Signal as Power+.
