Product Overview

Description

HS702 pneumatic pressure gauge comparator

HS702  pneumatic pressure gauge comparator consists of hand pump, lead screw, reverse valve, relieve valve and output interface. It features high sealing, stable pressure generating and simple operation. It is suitable in the laboratory and fieldwork. It provides pressure measurement for calibrating pressure (differential pressure) transmitter, precision pressure gauge, general pressure gauge and other pressure instruments.

Functions
HS702 provides pressure measurement for calibrating pressure gauges such as pressure (different pressure) transducers, precision pressure gauges, general pressure gauges and other pressure gauges. It can be extensively used in power, chemical, petrol, metallurgy, metering, military industry, etc.

Characteristics
- Food grade stainless steel, hermetic technology in the military industry.
- Built-in air oil separator could discharge the greasy dirt of the inspected instrument
- High accuracy, simple operation, convenient maintenance.
- No external pipeline to avoid the changing influence from the outer environment.

Technical Specification

Pressure Range	(-0.95~ 25) bar
Work Media	air
Output Interface	M20×1.5
Overall Dimension (L×W×H)	325mm×210mm×170mm
Weight	2.7Kg
