60 seater  EQ6105P3G 10 meters long  luxury buses for sale

EQ6105P3G Technical Specification
Chassis Model EQ6101RC3G1 Bus Model EQ6105P3G
 Dimension  Length(mm) 10490 Engine  Engine model YC6A240-30
Width(mm) 2500 Fuel type Diesel
Height(mm) 3250 Discharge standard  Europe 3
Internal Heigh(mm) 2260 Engine location Rear location
Wheelbase(mm) 5000 Compression ratio 17.5  1
Tread(front/rear,mm) 2020/1860 Maximum power 177/2300
Front overhang/rear overhang(mm) 2400/3090 Max   Torque  900/1000-1800
Minimum ground clearance(mm) ≥180 Performance parameters Fully-loading)braking distance ≤10
Approach angle/departure angle(°) 7/7 Fuel consumption limit condition(L/100km) ≤25
Displacement 7.255 Max speed 90
Quality parameters Unladen mass(kg) 10050 Gradeability largest (%)  ≥30
UMAX mass(kg) 15,000 Min turning Diameter ≤18
UFully loading mass(front/rear,kg) 5000/10000 Oil tank capacity(L) 310L
Items Body configuration
 Chassis spec. Clutch  Φ 430mm diaphragm spring,hydraulic pressure remote,with clutch booster;
Transmission QJ-ZF gear box QJ1205; Odometer gear ratio 10:3; Flexible shaft wire drawing control
 Front axles/rear axles  DONGFENG DANA  Axles (Forged  steel Material ) Axles load capacity  5500kg
DONGFENG DANA Axles, load capacity10000kg
Suspension system Few spring suspension, front 3/rear 4;  Front and rear Suspension with horizontal Stabilizer Bar
Steering system Power steering, Steering wheel position can be adjust
Braking system split braking system,drum brake,energy storage spring brake ,Automatic gap adjustment arm;
with Dryer,
Auxiliary Brake: WABOC ABS                             Option E-turbo retarder
Tires 10.00R20 radial tire
Dynamotor 90A,28V
Body Spec. Interior Softening treatment,aircondition Interior
Passenger's door  Pneumatic door
Flooring Aluminum Floor with 2mm thickness
 Driver's seat Damping driver seat, adjustable high back reclining chair
 Passenger seat Youbang brand GJ-08B model  39 seats with cushion    ( 2+2  layout)
Audiovisual system radio+ 17'LED +DVD + MP5 player
Rearview mirror  Electrical  rabbit ear type rearview mirror
Internal Rearview mirror
Lamp Integral front and rear headlights
Windscreen wiper, Opposed windscreen wiper
Paint Metallic Paint as per customer requirements deign.
Pattern To be determined
Others Spec. Driver's Sunshade Curtains, Side Sunshade Curtains
 Electricity/air horn , Electric fan, Engine cover, Cigar Lighter
Triangle warning plate,Electronic clock , Fire extinguishers ,Safety hammer(four units)
Two Security window with fan.(DS750C)

picture 02picture 01









Packing and shipping

shipping



Company Profile:

new bus factory



Client visit

bus client new1



Hot bus

new hot bus.jpg





Packaging & Shipping


FAQ

1.What is the warranty?

You can enjoy technical support by phone or email forever.We will provide a prompt solution.We also offer the most convenient and efficient spare parts support with competitive price.

2.What is the delivery time?

The delivery time is usually within 35 workdays after we received your prepayment.

3.Do you provide customized service?

Yes, we offer customized service as you need for the performance,including special requirements.

4.What is the payment method?

TT 30% as deposit, balance before shipment by TT or L/C at sight.

5.Why us?

We guarantee professional one-stop service,competitive price with high performance.
