ZMK2135x12m Tube Honing Machine Tool Hydraulic Cylinders Honing Machine
- Category: Honing Machines >>>
- Supplier: Taizhou Hitech Nc Machine Tool Co. Ltd.
Share on (847662246):
Product Overview
Description
Quick Details
| Port: | Qingdao port |
| Payment Terms: | L/C,D/P,D/A,T/T |
| Supply Ability: | 100 Set/Sets per Year Hydraulic Cylinders Honing Machine |
| Weight (KG): | 6000 |
| Center rest clamping Diameter range: | 100-420mm |
| color: | optional |
| Range of feed speed: | 5000~20000mm/min(stepless) |
| After-sales Service Provided: | Engineers available to service machinery overseas,Online support,Video technical support,Free spare parts,Field installation, commissioning and training,Field maintenance and repair service |
| Dimension(L*W*H): | 14000x2200x1900mm |
| Warranty of core components: | 1 Year |
| Flow of coolant pump: | 100L/min |
| Power(W): | 17kw spindle motor |
| Key Selling Points: | Long Service Life |
| CNC or Not: | CNC |
| Voltage: | 380V |
| function: | metal deep hole honing |
| Local Service Location: | None |
| Machinery Test Report: | Provided |
| Condition: | New |
| Place of Origin: | Jiangsu China |
| Warranty: | 1 Year |
| Showroom Location: | None |
| Certification: | ISO |
| Weight: | 60T |
| Power (kW): | 50 |
| Brand Name: | HITECH |
| Video outgoing-inspection: | Provided |
| Core Components: | PLC,Engine,Bearing,Motor,Pressure vessel,Gear,Pump |
| Marketing Type: | Ordinary Product |
| Applicable Industries: | Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Food & Beverage Factory,Construction works ,Energy & Mining |
| Speed range of honing rod box: | 20~200r/min(two gears stepless) |
| After Warranty Service: | Video technical support,Online support,Spare parts,Field maintenance and repair service |
| Packaging Detail: | Plywood case and water-proof cloth for the package of hydraulic cylinders honing machine |
