washing machine spin motor 60w

Product Overview

Description

washing machine spin motor 60w

1: high performance at competitive prices
2: 110/220V 50/60hz
3: 30-220w
4: capacity 5-12kg

5: shaft size : 10-43mm

6: long life





Wash motor
model	rated power	voltage	frequency	current rating	starting torque	greatest torque
CW-W80	80W	220-240v 110-127v	50/60Hz  60Hz	<=0.85A       <=1.5A	>=0.7Nm	>=1.0Nm
CW-W100	100W	220-240v 110-127v	50/60Hz  60Hz	<=1.1A       <=2.2A	>=0.8Nm	>=1.30Nm
CW -W120	120W	220-240v 110-127v	50/60Hz  60Hz	<=1.15A       <=2.2A	>=0.85Nm	>=1.50Nm
CW -W130	130W	220-240v 110-127v	50/60Hz  60Hz	<=1.3A       <=2.5A	>=0.90Nm	>=1.55Nm
CW -W150	150W	220-240v 110-127v	50/60Hz  60Hz	<=1.4A       <=2.8A	>=0.95Nm	>=1.70Nm
CW -W180	180W	220-240v 110-127v	50/60Hz  60Hz	<=1.6A       <=3.5A	>=1.2Nm	>=2.30Nm

spin motor
model	rated power	voltage	frequency	current rating	starting torque	greatest torque
CW-WS30	30W	220-240v 110-127v	50/60Hz  60Hz	<=0.5A       <=0.95A	>=0.32Nm	>=0.45Nm
CW-WS40	40W	220-240v 110-127v	50/60Hz  60Hz	<=0.58A       <=1.10A	>=0.38Nm	>=0.50Nm
CW-WS45	45W	220-240v 110-127v	50/60Hz  60Hz	<=0.65A       <=1.3A	>=0.42Nm	>=0.56Nm
CW-WS60	60W	220-240v 110-127v	50/60Hz  60Hz	<=0.75A       <=1.5A	>=0.50Nm	>=0.75Nm
CW-WS70	70W	220-240v 110-127v	50/60Hz  60Hz	<=0.8A       <=1.5A	>=0.53Nm	>=0.82Nm
CW-WS90	90W	220-240v 110-127v	50/60Hz  60Hz	<=0.95A       <=1.8A



CW-WS120	120W	220-240v 110-127v	50/60Hz  60Hz	<=1.1A
CW-WS70	150W	220-240v 110-127v	50/60Hz  60Hz	<=2.1A



The motors can be customized according to the different voltages , freqencies and rotation speed .

copper wire , aluminume wire and copper wire mix aluminume wire are available

we can develop new products according to the customers demands



















Item	spin motor 60w
sample	within one week
guarantee / warranty	1 year
price	competitive
delivery time	15-30 days
port	ningbo / shanghai
certification	ROHS UL CE CCC ISO
oem	available



Contact us : welcome to visit us for checking 2013 latest products
