Square, Round, Oval Shape Products Charcoal Ball Extruder

Product Overview

Description

Technology Information for Charcoal Ball Extruder



model	motor power(kw)	capacity (t/h)	speed radio	Roller diameter(mm)	weight(t)
290	5.5	1-2	1:12.26	290	0.75
360	7.5	2-4	1:23.34	360	1.67
400	13	4-6	1:23.34	400	2.7
500	22	5-8	1:31.5	500	4.1
650	30	8-12	1:31.5	650	5.7
750	55	12-15	1:31.5	750	8.9
800	75	15-18	1:31.5	800	11



Main raw materials which can be used in charcoal ball extruder



1 coal dust,charcoal powder,coal slurry,coking coal



2 dusting ash,pond slob,fire coat,steel slag,iron fine power,aluminum ash powder,silicomanganese mineral powder,ect.



Two types of the equipment



1. Two Rollers



This type of briquette press has two larger rollers in a fixed position in the frame, the other two smaller rollers are moveable. As its named implied, it has four rollers and press briquettes for twice times, so it make briquettes stronger and in higher density. This machine is national patent product in China.
The output briquette is in high quality and strong (not easy broken) that won't be broken when dropped from 150-250cm height. Meanwhile, it is easy for combustion, no smell and last longer when burning.





2.Four Rollers



Four-roller machine working principle is that the two vice-roll pre-suppress materials in the form of pipeline to lay a solid foundation for the finished ball. For finished products heroes ball solid foundation. After the main roll for feeding and secondary pressure, the pressure of materials multiplied, squeeze the ball more solid product. Reached a multiplier effect. Loose on the local materials, such as coke, iron skin, dust powder effects of sludge and other materials is very obvious.



Main advantages of the charcoal ball extruder



1 Low cost and consumption

2 Easy to operate

3 Final products are in high quality





 If you are interested in this Charcoal Ball Extruder, welcome to contact with me freely as the followings:
