Product Overview
Description
Marine Boat Steel/Aluminum Vertical Ladder
The vertical ladder is the way from rooms to passageway or from passageway to passageway between decks on ship. The design of our vertical ladder is totally in accordance with the ISO standard, IMO standard, and kinds of Classification Society's requiremnt.
Therefore, ABS, DNV, CCS, NK, LR, GL, BV, RINA are available for our products.
| Material | Steel, Aluminum Alloy, Fiberglass | |||||
| Step | Non-Skid Serrated Steps / Burr-Punched Steps | |||||
| Rung Style | Double Rung/Single Rung | |||||
| Space Between Rungs | 300-350mm | |||||
| Handrail | Optional Handrail for Requirements | |||||
| Specification | ||||||
| Product No. | Step No | L | H | T | Weight | |
| B=325 | B=400 | |||||
| MOUE040-SV001 | Optional step available | mm | mm | / | kg | kg |
| 800-5000 | 150-250 | 6,8 | 3.65-12.8 | 3.73-13.28 | ||
| Available in various sizes, please specify your requirement to us. | ||||||
