liquid anhydrous ammonia

High grade

First class

Standard

NH3 %≥

99.8

99.8

99.6

Residuum %≤

0.2

0.16

-

H2O %≤

0.1

0.07

-

Oil mg/kg ≤

5

1.6

-

Fe mg/kg ≤

1

0.7

-

Name

Unit

Parameters

LPG brand

/

CLW

Tanker model

/

CLG2400-60

Tanker volume

L

60,000

Tanker loading

MT

25.2(For propane)

Tanker material

Q345R

Tanker vechicle size

/

11657×2632×3028

Tanker DD

/

2600

Tanker Curb mass

kg

10960

Design pressure

Mpa

2.16

Design temperature

°C

-19--50

Filling factor

/

0.42

Corrosion allowance

mm

1

Heat treatment

/

overall

Water pressure test

Mpa

3.12

Tightness pressure test

Mpa

2.16

The thickness of the cylinder

mm

14

The head thickness

mm

13.53

Tanker life

Years

10

Level meter

Model

UHZ-518C14

Norimal pressure

2.5Mpa

Measurement range

50-2300mm

Accuracy

2.5

Safety valve

Model

A42F-2.5-80

Nominal

2.5 Mpa

Nominal diameter

DN50

Opening pressure

1.68-1.76 Mpa

Back seat pressure

≥ 0.8 times the opening pressure

Nominal diameter

Into the liquid pipe

DN80

A liquid pipe

DN80

inlet

DN50

Outfall

DN80

Vent port

DN80
