The SNM012C-06, with 6 wires and compact 13.00mm body diameter, which we call our “mini”, is our newest design and smallest physical package.uses SenRing's fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates.
SNM012C-06 Dimensions
SNM012C-06 Specifications
Contact Material
Gold alloy brush,Gold plated rings
Current Rating
2A, per ring, maximum
Number of Circuits
6
Operating Speed
250 rpm* continuous
Housing Material
Engineering Plastics
Lead Wire
UL Teflon® Awg28,color-coded, silver-plated
Lead Lengths
250mm
Voltage
210 VDC / 240 VAC
Operating Temp.
-40°C to 80°C
Torque
Approx. ≤0.3 g·m (for reference )
Dielectric Strength
≥600V@50Hz between each circuit
Insulation Resistance
600MΩ@ 300VDC
Noise
18 milliohms maximum tested @ 6 VDC, 40 milliamps when running @ 5 - 15 rpm
Resistance to pull
Radial 2KG,Axial 0.5KG
Protection
IP51
*Please note that the operational life of the unit is dependent upon rotational speed, environment and temperature
Description
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure.The SNM012C-06, with 6 wires and compact 13.00mm body diameter, which we call our “mini”, is our newest design and smallest physical package.uses SenRing's fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. SNM012C-06 is Compatible with data bus protocols,Transfers analog and digital signals.
Features
6 circuits
Compact size: 13.00mm(diamter)*18.2mm(L)
Gold-on-gold contacts
Compatible with data bus protocols
Transfers analog and digital signals
Speeds up to 250 rpm continuous
Precision ball bearings meet or exceed life requirements for most commercial applications
