PVC Shrink Tube For Battery

Product Overview

Description

PVC heat shrink tube for battery:
PVC heat shrinkable tubing possesses excellent flexibility, mechanical and dielectric capability, flame resistance, low temperature shrinkage etc.
It is widely applied in outside insulating protection of outgoing wires of electrical appliances, motors, sensors and transformers, bunchy wires
and electronic components, gaseous and liquid pipelines etc.

 PROPERTY(Wall thickness:0.10-0.12mm)

Property	Test method	Standard
Tensile strength		≥4000Pa/m2
Dielectric voltage withstand	10seconds	≥8KV
Volume resistivity	Normal temperature  Relative temperature≤65%	≥1015Ω/cm3
Resistance to second shrinkage	185°C     15seconds	≤20%
Resistance to second shrinkage	Dipping in 160°C silicone oil after recovered with capacitor for 3 minutes









Remark: Flat width ≤70mm, Thickness 0.05mm



               Flat width ≥70mm, Thickness 0.08mm



               Other size can be customized.
