ZXJP 216 Computerized Fabric Pleating Machine

Product Overview

Description

ZXJP-216 Computerized Fabric Pleating Machine



Characteristics
(1) ZXJP-216D is one of the latest computerized mechanical equipment with computer controlled system and can be easily operated.
(2) It can make vertical patterns, wave patterns, bamboo leaf patterns, etc of synthetic fabrics, blended fabrics, and leather… for clothing, bedding and various decorations.
(3) The direction and the number of pleats can be set in computer freely and easily. Compared with ZXJP-216, more pleating designs are available.



Specification:

Working Width	0~1600MM/3000MM
Pleating Speed	0~100 pleats/minute
Pleating Height	3~20MM
Pleating Width	≥3MM
Power Supply	380V (220V available)
Electric Consumption	9KW
Dimensions	3250 x 1600 x 1800 MM
Net Weight	1300KG



Samples:
