CNC gantry plate drill is a special CNC machine for drilling connection boards and base plates
of steel structure, tower, bridge and other industries.
| Model | TPD2012 | TPD2016 | TPD3016 | |
| Max size of work piece(mm) | 2000*1200 | 2000*1600 | 3000*1600 | |
| Max thickness of work piece(mm) | Max 100mm | |||
| Max drilling diameter | φ50mm | |||
| Morse taper | #4 | |||
| Drilling spindle | Rotating speed(rpm) | 120-560 | ||
| Max feed stroke(mm) | 350 | |||
| Motor power | 5.5 | |||
| Qty of clamps | 12 | |||
| Clamping force(kN) | 7.5 | |||
| Motor power(kW) | Servo motor X axis | 1.3 | ||
| Servo motor Yaxis | 1.3 | |||
| Servo motor Z axis | 0.85 | |||
| pump motor | 2.2 | |||
| Motor of scrap cleaner | 0.4 | |||
| Motor of cooling pump | 0.43 | |||
| Net weight(kg) | 5200 | 6200 | 7200 | |
| Dimensions(L*W*H)m | 4.5*2.21*2.85 | 4.5*2.61*2.85 | 5.5*2.61*2.85 | |
Main Features:
1. CNC slider and drilling unit head can control depth of holes, with function of drilling blind hole, reaming, and chamfer angle.
2. Machine is controlled by PLC servo motor, ensure precision positioning.
3. The machine have 4 work area with individual reference, 12 rapid hydraulic clamps, capable of clamping four sets of work pieces and downloading work pieces when drilling simultaneously. Workpieces can be clamped by hydraulic clamps at any area for drilling.
4. CNC, PLC systems, CRT display.
5. Programming software based on WINDOWS platform with CAD connection, fast and convenient programming, and visual previewing, it can use Auto CAD drawing directly, it also can process NC file which generated by TKLA.
6. Scrap cleaner can collect all iron scraps and cutting liquid which is recycling.
7. Key machinery, hydraulic pressure, electric components are chose from famous cooperation domestic and abroad.
8. Optimized integration design for complete machine, no foundation requirements.
