Nano and micron mill Paint Horizontal Sand Grinding Machine

Share on (950695974):


Price:

Quantity:


Product Overview

Description



Great cooling performance:
Materials can be pre-cooled between the guiding eddy gap. Materials can be cooled between the stator and rotator in the outer
milling chamber. Materials can be effectively cooled by the bottom of the stator. In the inner surface of the rotor, milling
chamber brings materials strong cooling with continuous eddy current movement.


Bead mill series:
1.WST wet dispersing nano bead mill, 2.WSK high viscosity superfine versatile bead mill, 3.WSJ horizontal internal cooling full
function bead mill 4.WSZ high viscosity horizontal bead mill, 5.WSS horizontal bead mill, 6.WSH high viscosity vertical bead mill,
7. WHD super fine bead mill, 8.WSV vertical internal cooling bipyramid bead mill. Note:different model bead mill for different
viscosity raw material and for different fineness result.


Application:
Ink,coat,paint,pigment,pesticides,medicine, dye,cosmetic,sensitive film, foods, electronic paste, Battery industry:cathode
materials of the lithium iron phosphate batteries, Digital consumptive materials:digital jet printing ink, Mineral
pigment:titanium pigment,calcuim carbonate,ferric oxide, Ceramic materials:alumina oxide,zirconia,silicon carbide, Rare-earth
materials:zirconia,indium oxide,cerium oxide,etc, Pharmaceutical preparation, Cosmetic:pearl power.


Model
Volume(L)
Medium size(mm)
Motor power(kw)
Capacity Max(L/H)
WHD-12
1.2
0.2-0.8
5.5
300 max
WHD100
11
0.2-0.8
22-30
1200 max
WHD200
25
0.2-1.2
45-55
3000 max
WHD400
35
0.2-1.4
90-100
6000 max
WHD800
80
0.2-1.4
250
12000 max
