Product Overview
Description
Led Lights Variable Message Sign Display Board Solar Traffic Amber Vms
Product Introduction
- Variable Message Signs,otherwise Known as VMS boaeds
- They are traditionally used in traffic management,road works and other projects
- The words are clearly and runs 24 hours a day,7 days a week,in any weather condition
- Trailer Signs deliver,set up and secure your VMS (electronic message board)
- We program your message remotely and can change it for free at any time
- Have street frontageTrailer Signs (Eletronic Message Boards)
- Also it will be a graet way to establish traffic management at your event,function or business site
Why choose us
China's leading solar traffic safety vision supplier
One unit can also customized,as long as you need .
Warranty 3 years ,local or remote service.
The affirmation of customers is our motivation.
Respectiong your every investment ,20 years of experience in global sales.
Product Parameters
| Trailer | Itme | Parameter |
| Material | Square steel tube(80*80*40 mm),8*8*4cm,channel steel customzied | |
| Color | Amber or orange/customized | |
| Fender | Good radians between wheels and fenders made it stable | |
| Damping spring | Double spring 750*50*5P,chassis shockproof protect the display | |
| Wheel | 175 / 70R13, bearing 675kg. Maximum speed 100KM / H, maximum load 1.5T | |
| Guide Pulley | Adustable lifting±30cm,load-bearing 2000LB(907K) | |
| Trailer Jack | 360 degree rotation,height:55cm,open height:85cm Rotate the handle to adjust the height of the car body support | |
| Trailer Size | 350W*2050H*2700D(mm) Specifications according to LED screen body | |
| Brake System | Non-brake or with brake or automatic- brake / customized | |
| Screen Rotation | 360 degree rotation of the screen, any point lock function / customized | |
| Rear Light Function | The electric brake is used together with the power source, and the turn signal, width indicator and brake light/customized | |
| Reflect Sheet | Customized | |
| Lifting System | The display screen has electric and hydraulic system lifting options,1200MM | |
| Draw Bar | Length:120cm/customized | |
| Trailer Speed Limit | 70KM/H | |
| Solar System | Solar Panel | 18V/250W * 2P mono-crystalline silicon solar panels |
| Solar Charge System | 60-100A charge manager and the mains charge management | |
| Battery | Lead-acid valve control battery 12V/250AH * 2P Warranty 3 years | |
| LED Display | Size | 1200W*1600H(mm)/customized |
| Brightness | ≥8000MCD/ M2 | |
| The consumption of energy | ≤800W/M2 | |
| Pixel Distance | P10/P16/P20/P33.3/customized | |
| Waterproof | IP35/58 | |
| Chip | Wafer/customized | |
| Software Control System | WIFI / computer / mobile phone / USP / USB and so on | |
