CNG Air compressors 200bar
- Category: >>>
- Supplier: Suzhou Yuda Compressor Co. Ltd.
Share on (958216477):
Product Overview
Description
Air compressor
1. Main data
Refuel your CNG vehicle at home
Benefits of using CNG
- Save running cost 30-50%
- Reduce on produced emissions
- Refill vehicle at home
Application to
- Car, van, commercial vehicle, truck, fork-lift etc
- Small fleets of taxi service, driving school etc
Small filling gas station
Model D-3 SPECIFICATION
Code | D-3 |
Flow rate | 3.5 Nm3/h 2 cfm |
Filling time | 3.5 hour for 60L tank(200bar 3000psi) 4.2 hour for 60L tank(250bar 3600psi) |
Working pressure | 200bar /3000psi or 250bar /3600psi |
Inlet pressure | Less than 0.3bar 4.5psi |
Motor power | EX 2.2kw/3.0hp 50/60hz, single phase |
Oil separator / oil filter | 1/1 |
Safety valve/ Alarm sensor | 1 in final/ option |
Time meter | 1 |
Starter | manual |
Switch | auto stop |
Emergency stop | manual |
Condensate / gas drain | manual |
Filling hose connect | 1 |
Dimensions (H-W-D) | 600-900-650 mm |
Weight | 125 kg |
Noise level | 60 db(A) |
Model D-5 SPECIFICATION
Code | D-5 |
Flow rate | 5.5 Nm3/h 3.5 cfm |
Filling time | 2.2 hour for 60L tank(200bar 3000psi) 2.7 hour for 60L tank(250bar 3600psi) |
Working pressure | 200bar /3000psi or 250bar /3600psi |
Inlet pressure | Less than 0.3bar 4.5psi |
Motor power | EX 3.0kw/4.0hp 50/60hz, three phase |
Oil separator / oil filter | 1/1 |
Safety valve/ Alarm sensor | 1 in final/ option |
Time meter | 1 |
Starter | manual |
Switch | auto stop |
Emergency stop | manual |
Condensate / gas drain | manual |
Filling hose connect | 1 |
Dimensions (H-W-D) | 600-900-650 mm |
Weight | 130 kg |
Noise level | 60 db(A) |
Model D-15, D-28 SPECIFICATION
Code | D-15 | D-28 |
Flow rate | 15 Nm3/h 9 cfm | 28 Nm3/h 17 cfm |
Filling time | 48 minutes for 60L tank(200bar 3000psi) 55 minutes for 60L tank(250bar 3600psi) | 20 minutes for 60L tank(200bar 3000psi) 25 minutes for 60L tank(250bar 3600psi) |
Working pressure | 200bar /3000psi or 250bar /3600psi | 200bar /3000psi or 250bar /3600psi |
Inlet pressure | Less than 0.3bar 4.5psi | Less than 0.3bar 4.5psi |
Engine power | EX 5.5kw/7.5hp 50/60hz three phase | EX 11kw/15hp 50/60hz three phase |
Oil separator / oil filter | 2/1 | 2/1 |
Safety valve/ Alarm sensor | 1 in final/ option | 1 in final/ option |
Starter/ Time meter | Manual/1 | Manual/1 |
Switch/ Emergency stop | Auto stop/ 1 | Auto stop/1 |
Condensate / gas drain | manual | manual |
Filling hose connect | 2 | 2 |
Dimensions (H-W-D) | 1100-1000-750 mm | 1100-1000-750 mm |
Weight | 190 kg | 200 kg |
Noise level | 72 db(A) | 72 db(A) |
Simple installation and operation, low service cost .anti-explosive designed
of this compressor make it running in safety. Separate electric controller
equipped. It is an ideal unit for filling 2 vehicles at same time, for outdoor
and indoor use
