ZH-880BFT Envelop Folder Gluer Machine
Feature
1.The machine is running steady with strengthened single-side driving system, and it is also easy for maintenance.
2.The motor is controlled by a transducer (inventer) which is available for automatic timing. It is power saved and helps to work stably.
3.Paper is feed by several thick belts under the help of vibration motor. Feeding is continuous,exact and automatic with this system.
4.Grinders are provided in both sides of machine, to make gluing more stable and firm.
5.Two sets of gluing units: top unit for bottom glue and lower unit for the side glue. All standard glue units apply line glue. Space adjustment is through the tooth rods.
6.PLC system and touch screen for easy operation. Out-put quantity/speed/counting etc., is able to set by this system. A remote diagnosis helps to maintenance (remote controller system included), and a photo electric system for speed control in pressing unit (speed in pressing unit is corresponding automatically with the one in feeding unit). Counting through photo-electric sensor & electromagnet kicking.
7.Back Delivery unit use pressing sponge belts for pressing to ensure out-put in a perfect condition. A transverse paper collection table after the pressing unit helps to collect boxes quickly.
8.The machine is able to make 2-fold or 4-fold crash-lock bottom boxes. In the pre-folding part, the 1st fold at 180°, the 3rd fold at 90°, the 2nd & 4th fold box at 180°.
9.Small box like out-put size at 30mm is able to be done after the special design according to customer requirement.
1. Main Technical Parameters:
1 | Line speed | 0-180m/min , Continuous adjustment |
2 | Usage paper | 250-500 g/ms, paperboard |
3 | Box forming | Bottom-lock, straight line box, double walls box |
4 | Fold method | 1st folds 180°, 3rd folds 90°, 2nd & 4th folds 180° |
5 | Paper feeding | Automatic feeding, grinding unit |
6 | Electric Power | 5.5kw |
7 | Dimension | 9.0*1.15*1.15m |
8 | Weight | 2350kg |
9 | Condition | New |
Box Type | Picture | A Max | A Min | B Max | B Min | C Max | C Min | D Max | D Min |
Crash-lock Bottom Box |
| 520-210mm | 580-220mm | 120mm | 30mm | ||||
Straight Line box |
| 580-110mm | 580-90mm | ||||||
Double Walls Box |
| 380mm | 500mm | 100mm | 300mm | ||||
Optional Equipment
Germany hhs Spray Gluing System Cold Glue Chinese Spray Gluing System Cold Glue
Chinese Plasma Surface Treatment System
One Gun Tow Guns Three Guns
Packaging & Shipping
Company Information
We Wenzhou Hoson Printing Machinery Co., Ltd ( Hongye Factory) started in 1990s, who is the earliest manufacturer of folder and gluer machinery in Wenzhou,Zhejiang,China
Through about 15 years' efforts, a mode integrated with production-sale-service has been built and completed.
Our main series of folder gluers are 4/6 corner type, crash-lock bottom type, pre-folding type and two-fold type, etc. We have these advantages: special design, easy operation, quick adjustment and high automation.
Our Services
According to the customer's requirement, we will arrange one technician to help you to install the machine and train the worker, but all the expenses like round-trip air tickets, accommodation, meals and salary USD80/day, incurred therefrom shall be born by the buyer.
Warranty
Warranty: one year. The manufacturer will send the buyer new parts ( no intentional damage). However, the courrier should be covered by the customer. Please note that the belts are excluding the one year's warranty.
