CE passed 10 cues 500M wireless control sequential & salvo fire consumer fireworks display firing system
- Category: >>>
- Supplier: Liuyang Pioneer Import And Export Trading Co. Ltd.
Share on (971296105):
Product Overview
Description
Product Description
Battery | 3 pcs 4.2V Li battery, output voltage is 12.6V | ||||||
Feather | With Test function | ||||||
Igniters | Can fire talon igniters and electric igniters | ||||||
Avantage | Programmable and interchangeable | ||||||
Control mode | Wire and wireless control mode, both okay | ||||||
Product Paramenters
DBR05-X1/10 /20 is a practical small size,a remote controlled electronic ignition of many fireworks products,using 1 million of non-repetition of the more secure codec technology,which allows the set off of fireworks can be tens of meters to a few hundred meters from the set off of wireless remote control,no ignition officers at close range ,have the function of a key with 10 groups at the same time set off and a key with 10 group scan be set up the time in chronological order to set off,makes the fireworks’see off of the most convenient, the best results.
Figures’Key | Interval（s） | |||
1 | 0.1 | |||
2 | 0.2 | |||
3 | 0.3 | |||
10 | 1.0 | |||
Item | Parameters | ||||||
Size(single group) | 9.2cmnx6cmx2.5cm | ||||||
Remote controller size | 12.5cmx4cx2.4cm | ||||||
Power | AAA(1.5Vx4) | ||||||
Power ofremote controller | 6F22 (9V) | ||||||
Safety testing current | ＜1MA | ||||||
The largest ignition current | 10A | ||||||
Number of remote controller | 1Pcs | ||||||
The most remote distance | ＞500M | ||||||
Usage:
1. Choose the right remote control lever toggle dial to select the set of points in number,press the launch button on the panel remote control and display the corresponding set of points,and the launch button plus one of automatic functions,the order of discharge only if the repeated manual pressing the launch button.
2. Slide Show to’--’,choose dial button is pressed together and launch capabilities,
3. Toggle to select the dial shows a group of 1-20 points to any number,press the select dial,display digital flash,this time for the sequential to display numbers in accordance with pre-flash interval set point font size,by group,from small to large ignition sequence (see table next time interval,)Blinking numbers returned again to select the dial set point control mode.
4. Upper left corner of the state of remote controller light is red,green,two colors,can be expressed for each set of points in
the state, number of dots under each group had not pressed the launch button when the green,or red,for the arbitrary choice determine the ser of points when the state of discharge.In the volley and the firing order of all the groups after the status indicator is red points(all in green when power on,power off without saving.)
1. Choose the right remote control lever toggle dial to select the set of points in number,press the launch button on the panel remote control and display the corresponding set of points,and the launch button plus one of automatic functions,the order of discharge only if the repeated manual pressing the launch button.
2. Slide Show to’--’,choose dial button is pressed together and launch capabilities,
3. Toggle to select the dial shows a group of 1-20 points to any number,press the select dial,display digital flash,this time for the sequential to display numbers in accordance with pre-flash interval set point font size,by group,from small to large ignition sequence (see table next time interval,)Blinking numbers returned again to select the dial set point control mode.
4. Upper left corner of the state of remote controller light is red,green,two colors,can be expressed for each set of points in
the state, number of dots under each group had not pressed the launch button when the green,or red,for the arbitrary choice determine the ser of points when the state of discharge.In the volley and the firing order of all the groups after the status indicator is red points(all in green when power on,power off without saving.)
Notes:
1. Do not placed the igniter in the water or in damp places.so as not to affect remote control’s distance een damage
1. Do not placed the igniter in the water or in damp places.so as not to affect remote control’s distance een damage
the igniter.
2. Turn on the power supply of igniter,power supply,lights,press the corresponding figure keys of the remote control,the power lights off,means the group remote control work normal,if press the remote control key long time,the power light flashing,then can judge and test each group of remote control.
3. As far as possible upward extension the receiving antenna to enable remote control receive farthest distance.
4. Normal connecting the ignition herd,testing lights,the can control the ignition,
5. If the igniter does not work,check the battery,if the distance of remote control received shortened,please check the remote control’s battery;If the remote control of a certain group can not control the ignition,please reconsider the code (see the notes on igniter).
6. The produce only for the set off of fireworks interval timetable for the order of set off
2. Turn on the power supply of igniter,power supply,lights,press the corresponding figure keys of the remote control,the power lights off,means the group remote control work normal,if press the remote control key long time,the power light flashing,then can judge and test each group of remote control.
3. As far as possible upward extension the receiving antenna to enable remote control receive farthest distance.
4. Normal connecting the ignition herd,testing lights,the can control the ignition,
5. If the igniter does not work,check the battery,if the distance of remote control received shortened,please check the remote control’s battery;If the remote control of a certain group can not control the ignition,please reconsider the code (see the notes on igniter).
6. The produce only for the set off of fireworks interval timetable for the order of set off
Related Products
Packing&Shipping
♦ Fast shipping &door to door -- most of our goods can be send by DHL/Fedex or TNT.
♦ Customized products by our factory.
♦ After-sale service -- On the premise that the products is not broken by purpose. The quality guarantee period is one year. We will repair or send you the replacement parts of the system during this period. We will not responsible for the broken by international shipping . If you found the package was broken, please take pictures of the goods before you open the box. And send it to the shipping agency in your city to get the compensation.
Our service
1.The express shipping agency is DHL, FedEx,TNT,UPS or EMS. It will send the goods to your door in 10-15 days normally. EMS is 20-25 days.
2.Import duties,other charges are not included in the item price or shipping charges, these charge are the buyer's responsibility.
3.Feedback is very important for us. please leave good feedback to us if you get satisfied with our goods and service. Please email us before leaving any negative feedback or opening any dispute on the site. We will help you to resolve the problem.
2.Import duties,other charges are not included in the item price or shipping charges, these charge are the buyer's responsibility.
3.Feedback is very important for us. please leave good feedback to us if you get satisfied with our goods and service. Please email us before leaving any negative feedback or opening any dispute on the site. We will help you to resolve the problem.
Company Profile
Liuyang Happiness Fireworks Co., Ltd. Located in Liuyang - the hometown of world fireworks, Hunan Province, China, our company has exported fireworks for over 10 years. Our products are sold far to Sweden, Poland, Russia, Italy, the United Kingdom, New Zealand, South Korea, the U.S.A, the Middle East, and other over 20 countries and regions. We have gained high praise from customers around the world. We have built different professional bases for various kinds of fireworks, such as cakes bases, rockets bases, shells bases, stage fireworks bases, and others. In addition, we are a manufacturer of fireworks firing systems and igniters. We can make sure that our products are of high & stable quality and our prices are favorable.Meanwhile, we can customize according to your market demand, and then you can have more advantages. We sincerely welcome the clients from all over the world to our company to take negotiation.
Certifications
FAQ
1. What the firing system power?
The receiver is powered by 4.2V rechargeable Li batteries, but the output voltage is 12V the remote controller is powered 9V battery, the remote controller is powered by 9V battery.
2. Control mode?
This is a remote control firing system, the remote distance is 500M.
The receiver is powered by 4.2V rechargeable Li batteries, but the output voltage is 12V the remote controller is powered 9V battery, the remote controller is powered by 9V battery.
2. Control mode?
This is a remote control firing system, the remote distance is 500M.
