Features: Plastic Extruder Machine Salesis a kind of special equipment for extruding of PVC powder. With different sorts of molds and auxiliary machines, it can produce all sorts of PVC plastic pipe material, profiled material, plate material, sliced material, bar material and granulation. It can also extrude PP.PE pipe at high speed by changing special barrel.
Computer control or conventional control is optional. According to customer's requirements, most reasonable screw can be made so as to achieve best plasticity state and material quality. The screw is made by high precision special digital screw miller, extruding property can be highly harmonized. It has firstly introduced advanced technique of producing screws with variable pitch and depth, so that the material can be more softly sheared and cut. The distribution box is specially designed, pull force bearing is fully imported, the drive life span can be prolonged. It can bear larger extruding pressure.
Model
SJSZ45/100
SJSZ51/105
SJSZ55/120
SJSZ65/132
SJSZ80/156
SJSZ92/188
(kw)Power of drive motor
15
18.5
22
37
55
110
(mm) Screw diameter
Φ45/Φ100
Φ51/Φ105
Φ55/Φ120
Φ65/Φ132
Φ80/Φ156
Φ92/Φ188
No.of screw
2
2
2
2
2
2
Rotational speed
36
36
36
36
36
36
Nm Torsional moment of screw
3148
6000
7000
10000
14000
32000
PVC Capacity PVC (kg/h)powder
70
100
150
250
400
750
Central height
1000
1000
1000
1000
1100
1200
Twin screw extruder:
Smart temperature:
With different auxiliary equipment can produce pipes, sheets, profiles:
Our company
Our Factory
What can we bringyou?
1. High- quality equipment and highly competitive market prices can bring you more profits.
2. More than 20 years of plastic extrusion machine industry experience, can solve
the various problems in the work. Improving machine efficiency for you.
3. More than 20 years of plastic extrusion machine industry experience, has
a good supply system, can provide you one-stop service with the pre-sale , sale and after sale service. Save your purchasing cost and maintenance costs.
Company Exhibtion:
Loading:
Contact
If you would like more equipment parameters and price , please contact me:
