A single mode optic fiber with low water peak, with a reduced sensitivity to bends for communication systems E3 (G657A1 /G652D)
Single-mode optical fiber with low water peak E3 (G657A1 /G652D) is a fiber with a reduced sensitivity to bends. The fiber is produced by vapor axial deposition method (VAD) with a quartz core alloyed with Germanium. It complies with the recommendations ITU-T G.652d completely and ITU-T G.657A1 with the parameters of macrobend loss and attenuation. It is a product manufactured in the Russian Federation. Double acrylic coating provides its high strength and a long service life. The fiber works in a full spectral range of different access networks, including FTTH, and can be applied in long distance communications. Fiber bending resistance and improved attenuation parameters give an advantage in the application for residential networks. The quality control system of the factory confirms plug compatibility with E3 fiber (G652d) manufactured by "Optic fiber Systems", JSC as well as with all standard SMF fibers. Fiber quality’s compliance with Russian and international standards is confirmed by the Certificate № SSAQ 025.1 .2.01 26 issued by certification agency "Kabelsert" of JSC "VNIIIKP" on 08.06.2018.
Dimensional Specifications
Dimensional Specifications
CoreClad Concentricity, μm | ≤ 0,5 |
Cladding Diameter, μm | 125±0,7 |
Cladding NonCircularity, % | ≤ 0,7 |
Coating Diameter, μm | 242±5 |
Fiber Curl, m radius of curvature | ≥ 4 |
CoatingCladding Concentricity, μm | ≤ 12 |
Length*, km | 25,2 / 50,4 |
*Supplies of other lengths are possible
Optical Specifications
Optical Specifications
Maximum Attenuation*, dB/km at wavelengths | ||
1310 nm | ≤ 0,32 | |
1383 nm | ≤ 0,32 | |
1550 nm | ≤ 0,18 | |
1625 nm | ≤ 0,2 | |
Attenuation vs. wavelength | ||
1285-1330 nm at wavelength 1310 nm | ≤ 0,03 | |
1525-1575 nm at wavelength 1550 nm | ≤ 0,02 | |
Point discontinuity, dB | ||
1310 nm | ≤ 0,05 | |
1550 nm | ≤ 0,05 | |
Mode Field Diameter, μm | ||
1310 nm | 9,2±0,4 | |
1550 nm | 10,4±0,5 | |
Cable Cutoff wavelength, (λсс ), nm | ≤ 1260 | |
Dispersion, ps/nm·km | ||
1550 nm | ≤ 18 | |
1625 nm | ≤ 22 | |
Zero dispersion wavelength (λ0 ), nm | 1300-1324 | |
Zero dispersion slope, ps/ (nm2 *km) | ≤ 0,092 | |
Polarization Mode Dispersion (PMD), ps/√km | ||
Maximum Individual Fiber PMD | ≤ 0,2 | |
PMD Link Design Value | ≤ 0,14 | |
** Attenuation coefficients in a wavelength range do not differ from attenuation coefficients at references more than indicated values
Macrobend Loss
Mechanical Specifications
Environmental Characteristics
Performance Specifications
Winding Conditions | Wavelength, nm | Induced Attenuation, (max, dB) |
1 turn around a mandrel of 10mm radius | 1550 | 0,75 |
1625 | 1,5 | |
10 turns around a mandrel 15mm radius | 1550 | 0,25 |
1625 | 1,0 |
Mechanical Specifications
ProofTest, GPa | ≥ 0,69 | |
(Other tension force on request) % | >1% | |
Coating Strip Force, N | ||
Peak force | 1 – 8,9 | |
Typical average force | 1 – 5 | |
Dynamic Stress Corrosion Susceptibility Parameter (Nd) | ≥ 20 | |
Environmental Characteristics
Induced Attenuation 1310 nm, 1550 nm & 1625 nm, dB/km | ||
60ºC ~ +85ºC Temperature dependence | ≤ 0,05 | |
+23ºC Water Immersion | ≤ 0,05 | |
+85ºC Heat Aging | ≤ 0,05 | |
+85ºC/85%Damp Heat | ≤ 0,05 | |
Performance Specifications
Effective Group Index of Refraction | ||
1310 nm /1383 nm | 1,466 | |
1550 nm | 1,467 | |
1625 nm | 1,470 | |
