Электрические заземляющие коннекторы для заземления из медного латунного сплава

Adjustable Earthing clamp as per BS 951 APPROVED EC 14, 15, 16 detailed as under: --

Ec 14-1, 15-1 & 16-1 applicable to dia 12-32mm
Ec 14-2, 15-2 & 16-2 applicable to dia 32-50mm
Ec 14-3, 15-3 & 16-3 applicable to dia 50-75mm

Series: 14 series is suitable for clean dry atmosphere & 15 & 16 series are suitable for all environments.

Terminal size: A-d is ment for 2. 5mm2 to 10mm2 conductor & a-e is ment for 2. 5mm2 to 16mm2 conductor. (adapted to conductor sizes upto 50mm2)

Customised clamps & large bends available as per drawings or samples or as per pipe dia.

- TENBY TYPE RAPID CLAMP OR PIPE CLAMP OR EARTH CLAMP TO BS 951 TEC14 & 15

- RADIATOR EARTH CLAMP WITH SPANNER TO BS 951 PHILEX OR SELECT TYPE USED WHILE PLUMBING APLICATION OR HEATERS.

EARTH TERMINAL BLOCK BS 2874 :-

- 4 WAY EARTH TERMINAL BLOCK: CONDUCTOR 1 X 25MM2 & 3 X 16MM2

- 6 WAY EARTH TERMINAL BLOCK: CONDUCTOR 1 X 25MM2 & 5 X 16MM2
- 8 WAY EARTH TERMINAL BLOCK: CONDUCTOR 2 X 25MM2 & 6 X 16MM2

PORCELAIN CABLE CONNECTORS AS PER RIKOO EU :-


- 5 AMP X 3 WAY SMALL.
- 30 AMP X 3 WAY LARGE.
- Range available from 5 Amp to 60 Amp 1, 2 & 3 & Customised

n Crimping type Copper Tubular Cable Terminal Bell Mouth Entry (cable lug with inspection hole Flared End) From 1. 5mm2 to 1000mm2

n  Earthing Crimp Lugs Bright electro Tin Plated to BS 1872 Material High Conductivity Copper to BS2871 Cable Dia 1.5mm2 to 1000mm2 for Earthing Terminal Application.

n Copper Ferrules & End Sealing Ferrules OR In Line Connectors.
Above Lugs / Connectors available as per BS, DIN & AWG Standard.

n Bi Metallic Termianl, Reducer Connectors, Stud Connectors Range

n Earthing Rod with Split Connector Clamp

n EARTH CONNECTING CLIP – SIZE : 15MM, 22MM, 25MM & CUSTOMIZED AS REQUIRED

n ADJUSTABLE EARTHING CONNECTION STRAP SIZE : 105 X 10 & CUSETOMIZED AS REQUIRED.

n DICONNECTING LINK HEAVY DUTY & ECONOMY MODEL

n STANDARD EARTH BAR AVAILABLE WITH SINGLE & TWIN DISCONNECTING LINK HEAVY DUTY SIZE AVAILABLE FROM 6WAY TO 30WAY & CUSTOMIZED AS PER DRAWING.

n COPPER ONE HOLE CABLE CLIP SIZE : 10MM TO 120MM & CUSTOMIZED AS PER DRAWING.

n SPLIT BOLT CONNECTORS – LINE TAPE

SIZE : 10MM2 TO 500MM2 & AWG RANGE UPTO 500MCM FOR CU/CU CONDUCTOR & CU/AL

CONDUCTOR & CUSTOMIZED CONNECTORS AVAILABLE AS PER DRAWING

- Low Isolation Bar - Earth Cut off Breaker

- High Isolation Bar - Earth Cut off Breaker

- T Shape Isolation Bar - Earth Cut off Breaker
- Earthing Clamp for Indoor Application
- Earthing Clamp for Out Door Application with Yellow Label
- Earth Inspection Port
- Hex Type Couplers 5/8 & 3/4 Heavy Duty
- Clamps 6-25 & 16-50 & Customized as per Drawing
- Bi Metallic Washer Round & Square as per Drawing.
- Stud / Nut Kit
- Earth Terminals Threaded complete Range from 16mm2 to 300mm2
- Earth Terminals with Multiple Poles for Earthing Indoor Application

- Split Bolt Connectors / Screw Threaded Terminal Range
- Copper Cable Lugs Standard & Heavy Duty with or without Inspection Hole available with Flared / Bell Mouth Entry in MM2, Din, AWG, Automotive Range & Customized Terminal as per Drawing.

- Bi Metallic Terminals, Reducer Connectors, Stud Connectors range & Customized   Connectors as per Drawing.
- Din Copper & Aluminium Lugs / Terminals Range

- C Connectors Range Regular /Customized as per Drawing.
- Sheet Metal Terminals O Ring Type, C type & Customized as per Drawing

- One Hole Cable Clip

- Disconnecting Link

- Earthing Bar with 1 & 2 Disconnecting Link up to 30 Way

- Adjustable Connection Strap

- Earth Connecting Clips

We can Develop / Manufacture Below mentioned Customized Range as per Drawing : -

Precision turned components,Terminals, Casting, Forging, Machining, Sheet Metal Parts as per Drawings without any Development Cost if its On Going / Regular Requirement.

Above Parts / Component / Finished Products available From BRASS, NAVAL BRASS, GUN METAL, SIL.BRONZE, PH BRONZE,  COPPER, ALUMINIUM, MILD STEEL & SS.

OEM & ODM Facility : Available

 Samples : Available for approval free

We assure best quality at most Competitive Price.

At your service 24 x 365.

BUYER'S BRAND

ASSORTED KIT BOXES

BLISTER PACK

INDIVIDUALLY BAGGED / PACK SIZE

BAR CODING

COLOR LABELS

CUSTOMIZED PACKING AS PER BUYERS REQUIREMENT

EXPORT SEA WORTHY HEAVY DUTY MASTER CARTOONS
