Лучший мотив XF8 88 клавиш синтезатор клавиатуры пианино

Описание и отзывы

Характеристики

MOTIF XF8 88-Key Music Production Synthesizer Specifications:

• Tone generator: AWM2, with Expanded Articulation


• Multi-timbral capacity: 16 Parts (internal), Audio Input Parts (A/D, FW*)


• *1 stereo Part


• Wave: 741 MB (when converted to 16-bit linear format), 3,977 waveforms


• Voice: Preset: 1,024 Normal Voices + 64 Drum Kits


• GM: 128 Normal Voices + 1 Drum Kit


• User: 128 x 4 (Bank 1: original, Bank 2 - 4: selected and copied from Preset bank) + 32 Drum Kits (No. 1 - 8: original, No. 9 - 32: selected and copied from Preset bank)


• Performance: User: 128 x 4 (up to 4 Parts)


• Filter: 18 types


• Effects system: Reverb x 9 types, Chorus x 22 types, Insertion (A, B) x 53 types x 8 Parts (up to 16 units), Vocoder x 1 (uses both Insertion Effect A and B blocks), Master Effect x 9 types (Preset settings for parameters of each effect type are provided as templates; total 320) Master EQ (5 bands), Part EQ (3 bands, stereo) Sampling block


• Samples: Up to 128 Waveforms (Multi Samples)


• Up to 256 Key Banks per Waveform


• Up to 512 Key Banks


• Sampling sources: Analog input L/R, Stereo output (Resampling)


• FW (available when the FW16E has been installed)


• A/D conversion: 24-bit, 64x oversampling


• D/A conversion: 24-bit, 128x oversampling


• Sample data bits: 16


• Sampling frequency: 44.1kHz, 22.05kHz, 11.025kHz, 5.5125kHz (Stereo/Mono)


• Sampling Frequency via FW (when the FW16E has been installed): 44.1kHz (fixed)


• Sampling memory: Internal SDRAM: 128M


• Sample length: Mono: 32 MB; stereo: 64 MB


• Sampling time:


• - 44.1kHz: 6 min. 20 sec.


• - 22.05kHz: 12 min. 40 sec.


• - 11.025kHz: 25 min. 20 sec.


• - 5.0125kHz: 55 min. 40 sec.


• *Mono/Stereo


• Sample format: Original format, WAV, AIFF


• Sampling sources: Analog input L/R, Stereo output (resampling) FW (available when the FW16E has been installed) Sequencer block


• Note capacity: Approx. 130,000 notes


• Note resolution: 480 ppq (parts per quarter note)


• Maximum polyphony: 124 notes


• Tempo (BPM): 5 - 300


• Recording type: Realtime replace; realtime overdub (with the exception of the Pattern Chain); realtime punch in/out (Song only)


• Tracks: Pattern: 16 Phrase tracks


• - Pattern Chain: Pattern track, Tempo track, Scene track


• - Song: 16 sequence tracks (Loop on/off can be set for each track), Tempo track, Scene track


• Patterns: 64 - Patterns (x 16 sections), Measures: 256 maximum


• - Mixing Voices: 16 Voices per Pattern and up to 256 Voices for all Patterns


• - Mixing Templates: 32 for all Songs and Patterns


• Phrases: User Phrases: 256 per Pattern


• Songs: 64 Songs


• - Mixing Voices: 16 Voices per Song and up to 256 Voices for all Songs


• - Mixing Templates: 32 for all Songs and Patterns


• Arpeggio: Preset: 7,881 types


• User: 256 types


• *MIDI Sync, MIDI transmit/receive channel, Velocity Limit, and Note Limit can be set.


• Scene memory: 5 per Song


• Sequence format: Original format, SMF format 0, 1 (Format 1 load only) Others


• Master: User: 128


• *8 Zones (Master keyboard settings), Assignable Knob/Slider settings, Program Change Table


• Sequence Software compatible with the Remote Control function:


• - For Windows: Cubase 4 - 5, SONAR 5.2 - 8


• - For Mac: Cubase 4 - 5, Logic 7.2 - LogicStudio, Digital Performer 5.1 - 6


• *Functions to be controlled differ depending on the software.


• Controllers: Pitch Bend wheel, Modulation wheel, Ribbon Controller, Assignable Control Sliders x 8,


• Assignable Knobs x 8, Assignable Function buttons x 2, Data dial


• Display: 320 x 240 dot, 5-11/16" graphic color backlit LCD


• Connectors:


• - Output L/mono, R (standard phone jack)


• - Assignable output L, R (standard phone jack)


• - A/D input L, R (standard phone jack)


• - Digital out


• - Phones (standard stereo phone jack)


• - Foot controller 1, 2


• - Footswitch X 2 (Sustain, Assignable)


• - Midi In/Out/Thru


• - USB (to host, to device)


• - AC in


• - Ethernet (100BASE-TX)


• IEEE1394 (available when the FW16E has been installed)


• Power consumption: 30W
