DN50 40Mpa кованые из нержавеющей стали 316 5000 фунтов/кв. дюйм высокое давление Гидравлический пневматический привод с 2 Путевым ПВХ шаровой клапан с пневматическим приводом
54 095,38-55 982,43 ₽
Шаровой кран из нержавеющей стали MNPT FNPT с внутренней и наружной резьбой
- Категория: Valves >>>
- Поставщик: Shenzhen Wofly Technology Co. Ltd.Shenzhen Ltd.
Сохранить в закладки 10000008453340:
Описание и отзывы
Характеристики
Product Description
Characteristics
Black handles with arrow indicate flow direction as standard，metal handles for option
Packing bolt allows easy packing adjustment
Panel mountable
Bi-directional flow.Micro-finished floating ball ensures leak proof shut off
End connections available with AFK tube end，BSPT or NPT female & male thread
FEATURES
On/off service ball valve with 2 way pattern
Diverter service ball valve with 3 way pattern
Body material in stainless steel SS316/316L
Max.allowed working preessure :50kg,3000psi,6000psi
With Fluororubber O-ring
100% factory tested
3PC BALL VALVE 50KG | ||||||
Item | Part Description | Qty. | Material | |||
1 | Handle | 1 | Nylon | |||
2 | Handle Set Screw | 1 | Chrome-Plated Steel | |||
3 | Stem | 1 | SS316/316L | |||
4 | Packing Bolt | 1 | SS316/316L | |||
5 | Gland Packing | 2 | TFM1600 | |||
6 | Stem O-ring | 1 | Fluororubber | |||
7 | Panel Nut | 1 | SS304 | |||
8 | Body | 1 | CF8M | |||
9 | Ball | 1 | SS316/316L | |||
10 | Seat | 2 | TFM1600 | |||
11 | Body O-ring | 2 | Fluororubber | |||
12 | End Cap | 2 | SS316/316L | |||
3PC BALL VALVE 3000PSI | ||||||
Item | Part Description | Qty. | Material | |||
1 | Handle | 1 | Nylon | |||
2 | Handle Set Screw | 1 | Chrome-Plated Steel | |||
3 | Stem | 1 | SS316/316L | |||
4 | Packing Bolt | 1 | SS316/316L | |||
5 | Gland Packing | 2 | SS316/316L | |||
6 | Stem O-ring | 1 | Fluororubber | |||
7 | Panel Nut | 1 | SS304 | |||
8 | Body | 1 | SS316/316L | |||
9 | Ball | 1 | SS316/316L | |||
10 | Seat | 2 | TFM1600 | |||
11 | Body O-ring | 2 | Fluororubber | |||
12 | End Cap | 2 | SS316/316L | |||
3PC BALL VALVE 6000PSIG | ||||||
Item | Part Description | Qty. | Material | |||
1 | Handle | 1 | Nylon | |||
2 | Handle Set Screw | 1 | Chrome-Plated Steel | |||
3 | Stem | 1 | SS316/316L | |||
4 | Packing Bolt | 1 | SS316/316L | |||
5 | Gland Packing | 2 | TFM1600 | |||
6 | Stem O-ring | 1 | Fluororubber | |||
7 | Panel Nut | 1 | SS304 | |||
8 | Body | 1 | SS316/316L | |||
9 | Ball | 1 | SS316/316L | |||
10 | Seat | 2 | PEEK | |||
11 | Spacer bracket | 2 | SS316/316L | |||
12 | Body O-ring | 2 | Fluororubber | |||
13 | Body O-ring | 2 | Fluororubber | |||
14 | End Cap | 2 | SS316/316L | |||
Specification
Ordering Information | ||||||||||||||
C- | 3 | BVL- | S6- | 02 | A- | 5K | ||||||||
Classification | Product Type | Valve Type | Material | Szie(fractional) | Szie(metric) | Connection Type | Max.Working Pressure | |||||||
C:Valve | 3:3PC | BVL:Castig Ball valve | S6:SS316 | 02:1/8" | 6:6mm | A:AFK tube end | 5K:50kg | |||||||
04:1/4" | 8:8mm | MR:Male BSPT Thread | ||||||||||||
06:3/8" | 10:10mm | FR:Female BSPT thread | ||||||||||||
08:1/2" | 12:12mm | MN:male NPT thread | ||||||||||||
012:3/4" | 14:14mm | FN:female NPT thread | ||||||||||||
16:16mm | ||||||||||||||
18:18mm | ||||||||||||||
20:20mm | ||||||||||||||
22:22mm | ||||||||||||||
Ordering Information | ||||||||||||||
C- | 3 | BV- | S6- | 02 | A- | 3P | ||||||||
Classification | Product Type | Valve Type | Material | Szie(fractional) | Szie(metric) | Connection Type | Max.Working Pressure | |||||||
C:Valve | 3:3PC | BV:2-Way Ball Valve | S6:SS316 | 02:1/8" | 6:6mm | A:AFK tube end | 3P:3000PSIG | |||||||
BVT:3-Way Ball Valve | S6L:SS316L | 04:1/4" | 8:8mm | MR:Male BSPT Thread | ||||||||||
06:3/8" | 10:10mm | FR:Female BSPT thread | ||||||||||||
08:1/2" | 12:12mm | MN:male NPT thread | ||||||||||||
012:3/4" | 14:14mm | FN:female NPT thread | ||||||||||||
16:16mm | ||||||||||||||
18:18mm | ||||||||||||||
Ordering Information | ||||||||||||||
C- | 3 | BV- | S6- | 02 | A- | 6P | ||||||||
Classification | Product Type | Valve Type | Material | Szie(fractional) | Szie(metric) | Connection Type | Max.Working Pressure | |||||||
C:Valve | 3:3PC | BV:2-Way Ball Valve | S6:SS316 | 02:1/8" | 6:6mm | A:AFK tube end | 6P:6000PSIG | |||||||
BVT:3-Way Ball Valve | S6L:SS316L | 04:1/4" | 8:8mm | MR:Male BSPT Thread | ||||||||||
06:3/8" | 10:10mm | FR:Female BSPT thread | ||||||||||||
08:1/2" | 12:12mm | MN:male NPT thread | ||||||||||||
14:14mm | FN:female NPT thread | |||||||||||||
Company Profile
WOFLY is a leading Manufacturer, Supplier and Exporter of a wide range of gas equipements, available under the brand name AFK. Wofly's success yields from high-quality, innovative products, exceptional customer service, and unequaled technical expertise in the gas& oil industry.
WOFLY offers an extensive line of components including tube fittings, control valves, shut-off and solenoid valves, pressure relief and regulators.Through the years we have learned how to properly match the gas regulation equipment with the application. Using the proper equipment for the job eliminates problems such as contamination, pressure variances, safety issues, and equipment mismatch.
WOFLY offers an extensive line of components including tube fittings, control valves, shut-off and solenoid valves, pressure relief and regulators.Through the years we have learned how to properly match the gas regulation equipment with the application. Using the proper equipment for the job eliminates problems such as contamination, pressure variances, safety issues, and equipment mismatch.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Southeast Asia(20.00%),Africa(20.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),South America(5.00%),Eastern Europe(5.00%),North America(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
pressure regulator,Tube fittings,solenoid valve,Needle valve,check valve
4. why should you buy from us not from other suppliers?
We have a couple of years with professional engineers and dedicated technicians.can provide security products for you
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
We are based in Guangdong, China, start from 2011,sell to Southeast Asia(20.00%),Africa(20.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),South America(5.00%),Eastern Europe(5.00%),North America(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
pressure regulator,Tube fittings,solenoid valve,Needle valve,check valve
4. why should you buy from us not from other suppliers?
We have a couple of years with professional engineers and dedicated technicians.can provide security products for you
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
