Высококачественный счетчик расхода колес из нержавеющей стали SUS для обработки воды

Описание и отзывы

Характеристики

The Paddle Wheel Flow Meter measures the flow velocity by using the fluidic to drive the blade rotation, and calculates the flow rate based on the flow velocity. ERP1 series flow meter consists of flow transmitter and pipe fitting. The light and compact design allows the user to carry, install and operate it conveniently.

The product is calibrated by professional flow test device, with the accuracy of K value reaching±3%. The measuring range is 0.3 ~10m/s, with high linearity. Display and non-display type are both available. The display type is built-in with accumulated flow storage device.

• Power supply: 12-36 Vdc.


• Analog output: 4-20mA with 10% higher range as 4-21.6mA


• Simulated test output: 0-24 mA.


• Pulse output: Optical-coupling transistor output.


• Simulated frequency output: 0-300Hz


• LCM (Graphic 128x64 Dots) display type


• Built-in FRAM (Ferroelectric Random Access Memory) flash memory


• LED indicator displays the alarm status.


• Upper limit settings of the analog output.


• Analog output flow rate and velocity filter settings: 0-40 segments.


• LED shows three back-lit modes, ON/OFF/In Operation.


• With RS485 communication.


• Parameter settings (K factor, pipe diameter, device ID, baudrate).


• Supports Traditional Chinese, Simplified Chinese, English, etc.

• Controlled by a microprocessor, with convenient operation and comprehensive functions.


• Easily separated from the sensor.


• Pure sensing non-display type is for convenient system integration


• Compact and lightweight structure, easy installation and maintenance


• High accuracy, up to ±3%









The Paddle Wheel Flow Meter is applicable to neutral or corrosive liquids that are non-granular or nonviscous.It connects with an analog output and pulse output signal to form a monitoring system, which can display instantaneous flow and accumulated flow. Moreover, it can form a control circuit to adjust the valve or operate the switch.

• Food industry


• Beverage industry


• Water treatment industry


• Pharmaceutical industry


• Dyeing industry


• Chemical industry


• Semi-conductor industry


• PCB wet process control
