Сверхмощный 40-футовый супердвойной тандемный бортовой прицеп-контейнер для угля в Монголии
834 956,43 ₽ - 889 174,38 ₽
Сохранить в закладки 10000016017009:
Type | Dump semi trailer | |
Semi trailer Dimension | 11280*2495*3970mm(can be customized) | |
Bottom plate thickness(mm) | 5mm-8mm Q235steel or can be optional | |
Lifting system | Full set of Hyva(FC214-5-07130)Hydraulic Lifting Cylinder | |
Main beam | Q345B Steel | |
Axle | 13T/16T,FUWA/BPW/Huajing Brand | |
Spring leaf | 90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12 | |
King pin | Jost brand 2.0 0r 3.5 inch bolts type or welding type | |
Landing Gear | JOST brand C200T or China brand 28Tons (Double speed) | |
Suspension | Mechanical suspension/America Type/Germany Type | |
Rim | 9.00-22.5/8.00-20/8.5-20China Brand | |
Tire | 12.00R22.5/315 80R22.5/11.00R20/12.00R20 Various tire brands are available | |
Pneumatic Braking system | WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber, 45L air tank | |
ABS | Optional | |
Tool box | One piece,1m*0.5m*0.5m(Size can be choose freely) | |
Painting | 1 coat of anticorrosive prime, 2coats of final paint | |
Any parts fitted could according to clients request, contact us to get more. |
