3 х осевой 100 т задний откидной полуприцеп погружной самосвал

Сохранить в закладки 10000016017009:


Цена:1 030 141,05 ₽ - 1 084 359,00 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики





Hydraulic Rear Dump trailer 3 Axles 40 cubic meter Tipper dumper Semi Truck Side Tipping Trailers


Product Description


ATUXCN Dump tipper semi trailers have different load capacities: 24 cubics, 30 cubics, 35 cubics, 45 cubics, We can customize the tipper trailers according to your special need.U-shaped dump semi trailer is used to transport of bulk cargo, coal, ore and build materials. The corner of U-shaped box doesn't exist dead ends, unloading more clean; Adopt T700 High strength plates to lower the tare weight; reduce the damage of ore head on the box; U-shaped structure of the lower center of gravity to avoid the goods spilled.




China Most Popular 40 Ton 50 Ton Tipper Trailer Rear Dumper Semi Trailer 4 Axles Used Dump Truck Trailer For Sale


Specification


Type
Dump semi trailer
Semi trailer Dimension
11280*2495*3970mm(can be customized)
Bottom plate thickness(mm)
5mm-8mm Q235steel or can be optional
Lifting system
Full set of Hyva(FC214-5-07130)Hydraulic Lifting Cylinder
Main beam
Q345B Steel
Axle
13T/16T,FUWA/BPW/Huajing Brand
Spring leaf
90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12
King pin
Jost brand 2.0 0r 3.5 inch bolts type or welding type
Landing Gear
JOST brand C200T or China brand 28Tons (Double speed)
Suspension
Mechanical suspension/America Type/Germany Type
Rim
9.00-22.5/8.00-20/8.5-20China Brand
Tire
12.00R22.5/315 80R22.5/11.00R20/12.00R20 Various tire brands are available
Pneumatic Braking system
WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber, 45L air tank
ABS
Optional
Tool box
One piece,1m*0.5m*0.5m(Size can be choose freely)
Painting
1 coat of anticorrosive prime, 2coats of final paint
Any parts fitted could according to clients request, contact us to get more.




Details Images






ATUXCN Dump Tipper Semi Trailer Advantage:
1.Double-plate main beam for heavy-duty dump trailer, which have stronger carrying capacity, it is not easy to damage.
2.Hydraulic cylinder: The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which makes the lifting more stable and does not easy to roll over.
3.Quality Axles and Brake system:BPW, FUWA worldwide best axles work with WABCO brake valve, more effectively brake for safe and save tire cost.
4.With 4 units vice beam and cross balance beam. The lattice structure of the side door makes the side door more solid.
5.Strengthened Ribs, unique structure design to maximize the payload.


Packing & Delivery




Company Profile




Established in 2023, SHANDONG KANYU IMPORT & EXPORT CO., LTD specializes in a wide spectrum of products ranging from automobiles, new energy vehicles, solar energy solutions, auto parts, to machinery and equipment. Our strategically located base in Jinan provided easy access, just a short half-hour trip from Jinan International Airport Shandong Province.
Dedicated to stringent quality control and attentive customer service, our experienced team ensures tailored solutions for every requirement, holding a TUV certificate and achieving success in both domestic Chinese markets and diverse international regions like the Middle East and Africa.
Our core expertise revolves around customizing trucks, tralers, and spare parts, with a strong focus on the supply chain management of Dongfeng trucks, other notable Chinese brands, specialized trailers, and authentic spare parts.





Customer Photos






Certifications




FAQ


Q: What’s your MOQ?
A: One unit

Q: Does your company has your own factory?
A: Yes, we have a factory ourself, which is in this business nearly 40 years in China.Our factory is very famous where is manufacturing various trailers in Shandong, China.

Q: Could you special design and produce for me?
A: Definitely! We have all kinds of professional engineers, could design and produce special product according to customer
requested. Such as: special Size, special control, or OEM, etc.

Q: Do you looking for Agent?
A: Yes, we're looking for the agent all over the world, please contact us for further discussion.

Q: How about your price?
A: Although we are brand name products,but our prices are very favorable and competitive. Customer from all over the world to purchase our products, because our best price.

Q: What's your payment term?
A: We accpet both T/T and L/C T/T: 30% deposit by T/T, 70% balance should be paid before shipment. L/C: 100% irrevocable Credit of Letter.
