CSA based cementitious materials is an ideal material for supporting and back-filling
In mining construction, due to its high strength, adjustable setting time, Good fluidity, especially for increasing the output of minerals such as coal and Gold. CSA is also an excellent matrix for making special high performance construction materials such as self-leveling material, grouting material, tile cohesive and repairing Material.

Specifications :

This binder was designed to be blended with Portland cement and anhydrite to make some dry-mixed mortars which need fast setting, rapid hardening, high-strength, freeze resistance, impermeability, corrosion resistance, low pH, low dry shrinkage and micro expansion properties.



Main constituents (%)

Component	37A	35A	34A
SiO2	≤7.0	≤8.5	≤10.5
Al2O3	≥36.5	≥35	≥34
Fe2O3	1.5-2.5	1.5-3.5	1.5-3.5
CaO	40.0-41.5	40.5-42.5	41.5-43.5
MgO	≤2.5	≤2.5	≤2.5
SO3	8.5-11.0	8.0-10.5	7.5-9.5
TiO2	1.0-2.0	1.0-2.0	1.0-2.0

























Fineness

Specific Surface Area: according to standard GB/T 8074-2008:



Usual range: ≥ 480 m2/kg, Specification limit: >450 m2/kg.



Hydraulic Properties

The characteristics of CSA BINDER have been tested in accordance with the Chinese standards: GB20472-2006.

Setting time determined at 20°C, using Vicat needle according to GB/T 1346-2001.

Mechanical strength at 20°C, 95% relative humidity according to GB20472-2006 .



Item		37A	35A	34A
Bending Strength (Mpa)	1d	≥8.0	≥7.0	≥6.0
	3d	≥10.0	≥9.0	≥8.0
	7d	≥11.0	≥10.0	≥9.0
Compressive strength (Mpa)	1d	≥60.0	≥50.0	≥50.0
	3d	≥85.0	≥75.0	≥65.0
	7d	≥95.0	≥85.0	≥75.0
Setting time	Initial	≥25min	≥25min	≥25min
	Final	≤300min	≤300min	≤300min







These properties are applied to obtain a wide range of products:

-   Rapid repair mortars

-   Fast setting tile adhesives

-   Fast setting tile grouts

-   Shot-crete / Gun-nite

-   External renders

-   Self smoothing mortars

-   Self leveling mortars

-   Anchor bolt grouts

-   Non shrinking grouts
