                                                           Metal hydride hydrogen Storage Tank


This product can absorb and desorb hydrogen at the room temperature and relatively low pressure, and more than 90% quantity of the hydrogen stored in it can be desorbed at relatively steady pressure in very steady hydrogen gas current. The hydrogen absorbing and desorbing pressure and the desorbing flow of the product depend on the users’ demand. Through the use of the product, the ordinary hydrogen can be purified into the ultra high pure hydrogen of 5 N purity, which indicates that the technology of the product has reached the international advanced level. The specifications of the product are defined with the amount of the desorbing hydrogen in standard state, which is from several liters to several hundreds of cubic meters. The shape of the product is generally cylindrical, and it can be adjusted with the users’ demand.

1.Small Size

Model

HYM-30S

HYM-50S

HYM-100S/A

HYM-300S

HYM-500S

HYM-750S/A

HYM-1000S

Capability of hydrogen storage

≥30 Liter

≥50Liter

≥100 Liter

≥300 Liter

≥500 Liter

≥750 Liter

≥1000 Liter

Measurement for reference (mm)

DIA40×L90

DIA 40×L130

DIA 46×L210/
DIA 57×L200

DIA 66×L310

DIA 78×L360

DIA 87×L450/
DIA 107×L430

DIA 100×L460

Gross Weight (kg)

≤0.9

≤1.2

≤2.5

≤5

≤8

≤15

≤17

Material of Pot

steel

steel

steel /aluminum alloys

steel

steel

steel /aluminum alloys

steel

Pressure of hydrogen storage

≤3 MPa

≤3 MPa

≤3 MPa

≤3 MPa

≤3 MPa

≤3 MPa

≤3 MPa

Time of hydrogen charging(25°C)

≤30 min

≤50 min

≤60 min

≤70 min

≤90 min

≤150 min

≤160 min

Released speed of hydrogen (25°C)

≥1 L/min

≥1 L/min

≥1 L/min

≥2 L/min

≥3 L/min

≥4 L/min

≥4L/min

2.Large Size

Model

HYM-5M

HYM-10M

HYM-30M

HYM-40M

HYM-50M

HYM-80M

Capability of hydrogen storage

≥5 m3

≥10 m3

≥30 m3

≥40 m3

≥50 m3

≥80 m3

Measurement for reference (mm)

DIA 300×L800

DIA 410×L900

DIA 520×L1520

DIA 600×L1500

DIA 630×L1680

DIA 550×L2100

Gross Weight (kg)

≤120

≤230

≤600

≤800

≤950

≤1000

Material of Pot

steel

steel

steel

steel

steel

steel

Pressure of hydrogen storage

≤3 MPa

≤3 MPa

≤3 MPa

≤3MPa

≤3 MPa

≤3 MPa

Time of hydrogen charging (25°C)

≤60min

≤60min

≤120min

≤120min

≤150min

≤150 min

Released speed of hydrogen (25°C)

≥20 L/min

≥35 L/min

≥60 L/min

≥80 L/min

≥90 L/min

≥200 L/min
