1.6 ton ZL16 with Cummins engine snow loader

Name: 1.6 ton ZL16 with Cummins engine snow loader
SKU: 1100000012892
Availability: InStock

Цена:*

Количество:

1.6 ton ZL16 with Cummins engine bridge construction equipment snow loader

1.4x4 Wheel Drive
2.Cummins Engine opertial
3.Joystick, color, optional
4. Fully hydraulic steering.

ZL16F main specification

Specification	overall weight(kg)	4400
	L×W×H(mm)	5700x1830x2730
	rated bucket capacity(m³)	0.8
	Rated load(kg)	1600
	Maximum dump height (mm)	5700x1800x2730MM
	Bucket indicator	Yes
	Max. breakout force(KN)	43
Engine	Model	WEICHAI4102 (Cummins engine optional)
	Type	In line,direct injection,four-stroke,liquid cooled
	Rated power(kw)	47kw
	Rated speed(r/min)	2200
Transmission system	Model of torque converter	YJ265
	Type	Single-stage,3 elements
	Gearbox type	Axial full power shift transmission
	Gear shift	2 gears ahead,2 gear astern
Hydraulic system	Distribution of work valve	DF15.2C
Hydraulic system	Working pump	CBG2040
Steering system	Type	Articulated hydraulic steering
	Max. turning angle	lift and right 35±1°
	Min turning radius(mm)	4200
Brake system	Brake type	Air assist oil disc on four wheel
Tyres	Standard tyres	22.5-16
