Techical Data


Customers Use


Why Choose Zhiyun Smooth 5?











| Tech Specs. | ||||
| Item | Min. | Standard | Max. | Remark |
| Operation Voltage | 6.5V | 7.4V | 8.4V | |
| Operation Current | 70mA | 3000mA | ||
| Charging Voltage | 5V | 9V | ||
| Charging Current | — | 1600mA | ||
| Output Voltage | — | 5V | — | |
| Output Current | — | — | 1A | |
| Following Deviation in Static State | ±0.01° | ±0.04° | ||
| Following Deviation in Motion State | ±0.05° | ±0.1° | ±0.3° | |
| Tilt Mechanical Range | -140° | 349° | 209° | Including storage state |
| Roll Mechanical Range | -90° | 300° | 210° | Including storage state |
| Pan Mechanical Range | -180° | 360° | 180° | |
| Controllable Tilt Angle | -90° | - | +170° | |
| Controllable Roll Angle | -50° | - | +50° | |
| Controllable Roll Angle | -180° | - | +180° | |
| Operation Temperature | -10℃ | 25℃ | 45℃ | |
| Charging Ambient Temperature | 0℃ | 25℃ | 45℃ | |
| Battery Capacity | — | 2600mAh | — | Built-in battery |
| Runtime | 4.5h | - | 25h | Lab Data 1 |
| Charging Time | 2h | - | 4h | Lab Data 2 |
| Payload | 150g | - | 280g | |
| Horizontal Arm Adjustment Range | -12mm | 47mm | 35mm | |
| Mounting Clamp Supporting Range | 50mm | - | 90mm | |
| EIRP | <3dBm | |||
| Operation Frequency | 2.402GHz~2.480GHz | |||
| Compatible Model | 1. Smartphones that their width is within the holder's capable width. 2. Smartphone Thickness<10mm | |||
