Product Description

IP55 IP65 30U outdoor telecom equipment cabinet 19 inch rack Enclosure

Outdoor telecom cabinet refers to a cabinet made of metal material, directly under the influence of the weather, and does not allow unauthorized operators to access. Base station equipment, power supply, battery, temperature control equipment, transmission equipment and other ancillary equipment can be installed in the cabinet, which can provide reliable mechanical and environmental protection for the normal operation of internal equipments. Outdoor telecom cabinet is mainly used in wireless communication base stations, including a new generation of 4G / 5G systems, communications / network integrated services, access / transmission switching station, emergency communications / transmission etc.

Product Features

· Sandwich panel construction
· Attractive powder coat finish
· 19’’ usable space 30U
· Anti-theft four-point outdoor cabinet lock, excellent keyhole protection device
· IP55 cabinet, walls and roof in double steel with high quality insulation
· Anti-theft four-point outdoor cabinet lock, excellent keyhole pr otection device
· High performance Air-conditioning unit for heat removal
· Door stopper to hold door open at service
· Pass earthquake intensity 8 anti-seismic performance test
· Support custom-made

Technical Data Sheet

Model	LAE1400	LAE1800	Customize
Internal Dimension(HWD)	1400650650MM	1800800800mm	7U~42U support customize /OEM/ODM
External Dimension(HWD)	1700750750MM	2100900900mm	/
Internal use space	30U	40U	/
Brand Name	Langji
Certification	ISO9001/ISO14001/CE/IP55
Material	Galvanized steel/Aluminum/stainless steel/Color coated steel
Color	RAL7035 GREY/Pantone428C/Custom
Door	one front door/ two doors
Structure	Welded/Frame/Assembly
Hinge	Embedded
Lighting	48V LED Lamp
Lock	4 point security lock
Equipment installation method	19’’ rack
Cable enter method	Bottom of the cabinet
Cooling	AC DC Cabinet air conditioner/Emergency Fans/Heat plate exchanger
Working temperature	-40～55℃
IP Grade	IP55/IP65/NEMA
Grounding protection	Cooper bar
MOQ	1 Unit
Package	Wooden case/ export pallet
Payment	T/T,L/C,Western Union
Warrenty	1 Year
Delivery time	15~20 working days

Accessory List(options)
No.	Item	Specification
1	Fan	DC48V Fan,work at 35℃
2	PDU	Garde B lightning proof AC INPUT:63A/2P 1 AC OUTPUT:16A/1P 4 DC OUTPUT:16A/1P *4 or customer requirement
3	Heat Insulation	Heat insulation between inner wall and outer wall. The insulation material is 20~45mm EPS or PVC/NBR.
4	Environment Monitoring Unit	48VDC Communication port:RS485,TCP/IP,SNMP optional
5	Door Sensor	Monitor door open status inside cabinet and provide real time alarm
6	Water Sensor	Monitor water status inside cabinet and provide real time alarm
7	Tilt & shock sensor	Monitor shock status inside cabinet and provide real time alarm
8	Temperature & Humidity sensor	Monitor temperature and humidity inside cabinet and provide real time alarm
9	Smoke sensor	Monitor smoke status inside cabinet and provide real time alarm
10	Built-in power supply	150A/200A/300A

Cooling System(Options)
1	Air conditioner	AC220V/DC48V, 300W,400W,500W,600W,800W,1000W,1500W,2000W,2500W,3000W,3500W,4000W;AC380V 5000W
2	Heat exchanger	AC220V/48V, 80W/K,100W/K,120W/K,150W/K,200W/K
3	Fan	DC48V

Product details

Product Application

Outdoor Telecommunication Cabinet is mainly used for wireless communication base station, including the new generation of 4G system, communication network/network integrated services, access/transmission switching station, emergency communication/transmission, etc.

Suzhou Langji a professional manufacturer outdoor telecom cabinet, cabinet air conditioner, plate heat exchanger over 13 years' experience. The products are certified by CE and CCC. Our products are sold in many countries and regions, including South-east Asia, the Russia, Europe, South America, the USA. Our excellent quality makes us enjoy a high reputation at home and abroad.

Our Exhibition

Packing & Delivery

Email	mina.zhu@szlangji.com
Phone Number	+86-15039286028
Wechat/Whatsapp/Skype	+86-15039286028
Tel	+86-512-66892668
Fax	+86-512-66592789
Manufacturer	Suzhou Langji Technology Co., Ltd.
Add	No. 58, Tongxin Road, Tongan Town, High-Tech Zone, Suzhou, Jiangsu province, China

FAQ

Q1.Do you have any MOQ limit for outdoor cabinet ?
A: Low MOQ, 1pc for sample checking is available.

Q2.What is your payment terms?
A: Normally our payment term is 50% advanced by T/T, Balance before shipment.

Q3: Are you a manufacturer?
A: Yes, we are a experienced manufacturer with our own design and production lines.

Q4: Can I get sample order?
A: Yes, we would like to get your sample order for testing our quality, the sample cost is paid by the customer.

Q5: Are you able to customize items with design or logo?
A: Yes, OEM & ODM is available.

Q6: How do you ship the goods and how long it will take?
A: We normally make shipment by EMS,UPS, Fedex, TNT, DHL or AIR for small order,which usually takes about 5-12 days. And by SEA for bulk order, which usually takes about 1-2 months depend on the destination.

Q7: What are the payment terms?
A: T/T, L/C, Trade Assurance, Western Union or others.

Q8: How long is the product warranty ?
A: We guarantee all our products 12 months warranty.

Q9: Can I visit your company and factory in China?
A: Pls call sales representative, we pick you up .or you can visit us anytime at factory address show in website.
