Оптовая продажа тип вентилятора 614HR постоянного тока осевой вентилятор

Описание и отзывы

Характеристики

1.PROPER USE The device is exclusively designed as a built-in device for conveying air according to its technical data. Any other usage above and beyond this does not conform with the intended purpose and constitutes misuse of the device. Customer equipment must be capable of withstanding the mechanical and thermal stresses that can arise from this product. This applies for the entire service life of the equipment in which this product is installed. Proper use also includes: Conveying of air at an ambient air pressure of 800 mbar to 1050 mbar.  Using the device in accordance with the permitted ambient temperature, see chapter 3.5 Transport and storage conditions and chapter 3.2 Nominal data. Operating the device with all protective features in place.  Minding the operating instructions. Improper use Using the device in the following ways is particularly prohibited and may cause hazards:  Operating the device with an imbalance, e.g. caused by dirt deposits or icing.  Resonance mode, operation with heavy vibrations. These also include vibrations that are transmitted from the customer system to the fan.  Operation in medical equipment with a life-sustaining or lifesaving function.  Moving solids content in flow medium.  Painting the device Connections (e.g. screws) coming loose during operation.  Moving air that contains abrasive particles.  Moving highly corrosive air, e.g. salt spray mist. Exceptions are devices that are intended for salt spray mist and protected accordingly.  Moving air that contains dust pollution, e.g. suctioning off saw dust.  Operating the device close to flammable materials or components.  Operating the device in an explosive atmosphere.  Using the device as a safety component or for taking on safetyrelated functions.  Operation with completely or partially disassembled or modified protective features.

2 Nominal data Motor M2S052-CA Phase 1~ 1~ Nominal voltage / VAC 230 230 Frequency / Hz 50 60 Type of data definition fa fa Valid for approval / standard CE CE Speed (rpm) / min-1 2800 3250 Power input / W 45 39 Current draw / A 0.31 0.25 Max. back pressure / Pa 80 120 Min. ambient temperature / °C -25 -25 Max. ambient temperature / °C 50 70 Starting current / A 0.45 0.40

3.Mass 1.1 kg Size 130 mm Motor size 52 Surface of rotor Rotor open, coated in black Material of blades Sheet steel, coated in black Material of wall ring Die-cast aluminium, coated in black Number of blades 7 Direction of air flow V Direction of rotation Counter-clockwise, seen on rotor
