Одноступенчатый всасывающий центробежный насос серии EK DIN24255/ISO9908, стандарт, латунное рабочее колесо, электроэнергия
28 837,53 ₽
Нержавеющая сталь санитарный SS304 SS316L пищевой высоковязкий насос с бункером для кунжутной пасты картофельного пюре и риса
- Категория: >>>
- Поставщик: Wenzhou Ace Machinery Co. Ltd.
Сохранить в закладки 11000015113026:
Описание и отзывы
Характеристики
Stainless Steel Sanitary SS304 SS316L Food Grade High Viscosity Pump With Hopper For Sesame Paste, Mashed Potatoes And Rice
22 Years Of Experience. Reasonable Price And Best Service, CE Certificated Products.Delivery within seven days.Sold to Over 180 Countries.Advanced Technology.Contact us for the offer.
Video
Products Description
Description:
Single screw pump is used in all fields widely to feed kind of medium, running at a constant pressure continuously, without pulse
and damage when feeding medium and change the gauging aim through adjusting rotation speed.
and damage when feeding medium and change the gauging aim through adjusting rotation speed.
1. High solid content(diameter of the biggest particle is 50mm)or no solid content
2. Medium with all viscosities(1mPas~3,000,000mPas)
3. Medium that is easy to be generated and swelled
4. Shearing sensitive medium
5. Medium with/without self lubrication
6. Erosive medium(PH=0~14)
7. Adhesive medium8. Toxicity hazard medium
Profile/type | Stainless steel food grade mono screw pump | ||||
material | SS304 or SS316L | ||||
Capacity | 0-100T (Customized) | ||||
Pressure | 0-8bar | ||||
High Viscosity | 1-100,000,00pas | ||||
Stator type | Rubber type | ||||
temperature | 0-80 celsius degree | ||||
connection type | Clamp | Union | Flange | ||
motor type | Normal | Ex-Proof | inverter | ||
motor cover | Round/Square | ||||
Speed | 0-960RPM | ||||
Technical Parameters | ||||||||
Model | FLOW(T/H) | Lift(M) | Speed(RPM) | Motor(KW) | ||||
ACE-10-M | 0.5 | 0-8bar | 1400 | 0.37 | ||||
ACE-15-M | 1 | 0-8bar | 960 | 0.55 | ||||
ACE-20-M | 1.5 | 0-8bar | 960 | 0.75 | ||||
ACE-25-M | 2 | 0-8bar | 960 | 1.1 | ||||
ACE-30-M | 3 | 0-8bar | 960 | 1.5 | ||||
ACE-35-M | 5 | 0-8bar | 960 | 2.2 | ||||
ACE-40-M | 7 | 0-8bar | 960 | 3 | ||||
5.5 | 0-8bar | 720 | 2.2 | |||||
ACE-45-M | 9 | 0-8bar | 960 | 4 | ||||
7 | 0-8bar | 720 | 3 | |||||
ACE-50-M | 13 | 0-8bar | 960 | 5.5 | ||||
10 | 0-8bar | 720 | 4 | |||||
ACE-55-M | 18 | 0-8bar | 960 | 7.5 | ||||
13 | 0-8bar | 720 | 5.5 | |||||
ACE-65-M | 30 | 0-8bar | 720 | 11 | ||||
ACE-85-M | 60 | 0-8bar | 720 | 15 | ||||
We Can Customize The Equipment According To Your Requirements. | ||||||||
Application:
Screw pump rotor for food industry is also called progressive cavity pump, Is widely used in
delivery of high viscosity products such as chocolate, syrup and jams etc.
Screw pump rotor for food industry is also called progressive cavity pump, Is widely used in
delivery of high viscosity products such as chocolate, syrup and jams etc.
Details Images
1.outlet 2.pulling 3.stator 4.screw shaft 5.cardan joint 6.inlet 7.coupling 8.feeding foundation 9.feeding bid 10.bearing pedestal 11.shaft 12.auxiliary 13.bearing bid 14.shaft coupling 15.foundation 16.motor
Packaging & Shipping
We are experienced in the whole packing and shipping process,and we will be responsible for any damage made during shipping and
send clients replacements for free.
* Sufficient inner protection with different materials, including bubble bag, foam board and others.
* Qualified wooden package or carton for different products or as customer require
* Strict packing process to ensure the safety and completeness of the goods
send clients replacements for free.
* Sufficient inner protection with different materials, including bubble bag, foam board and others.
* Qualified wooden package or carton for different products or as customer require
* Strict packing process to ensure the safety and completeness of the goods
Other pumps
Centrifugal pump
Centrifugal pump is a kind of high efficient and economical pump, because it can meet the requirements of health and soft
treatment of products, and has chemical stability, so it is only suitable for most of the health industry.
treatment of products, and has chemical stability, so it is only suitable for most of the health industry.
Homogenization pump
The machine disperses, shears and emulsifiers the material in shortest time, and the diameter range of the particles gets smaller
so that fine and stable produced.
so that fine and stable produced.
Lobe Pumps
Rotor pump is suitable for transporting high viscosity, ensity and any medium containing particle.
Certifications
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in plywood case or carton package for small parts.
If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T in advance, 30% as deposit, and finish 70% balance payment before delivery.
We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 3 to 4 weeks after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q6.Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
A: Generally, we pack our goods in plywood case or carton package for small parts.
If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T in advance, 30% as deposit, and finish 70% balance payment before delivery.
We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 3 to 4 weeks after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q6.Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
