Горячая распродажа от производителя 48 В 100Ah 200Ah 400Ah 5Kwh 10Kwh 20Kwh мощная литиевая батарея энергия железа солнечная для хранения дома с BMS
550,00-625,00 $
Smart BMS LiFePO4 5kwh 10kwh 20kwh 24V 48V 100Ah 200Ah 300Ah Lithium Ion Server Rack Mounted Battery Pack for Solar System
- Категория: >>>
- Поставщик: Jiangxi Xidong Export And Import Co. Ltd.Jiangxi Ltd.
Сохранить в закладки 11000019001496:
Описание и отзывы
Характеристики
Model | HZEB-HCT-5 | HZEB-HCT-10 | HZEB-HCT-15 | |||
Nominal Voltage | 51.2V | 51.2V | 51.2V | |||
Sell model/Configuration | 3.2V100Ah/16S1P | 3.2V206Ah/16S1P | 3.2V280Ah/16S1P | |||
Capacity(Ah) | 100Ah | 206Ah | 280Ah | |||
Rated Energy(kWh) | 5.12kWh | 10.55kWh | 14.34kWh | |||
Max.Charge/Discharge Current(A) | 50A/100A(For customiztion) | 100A | 100A/150A(For customiztion) | |||
Voltage Range(Vdc) | 44.8~57.6V | |||||
Scalability | 6 parallel(For customiztion) | |||||
Communication | RS232-PC,RS485(B)-BATRS485(A) | |||||
Cycle Life | z6000Cydes@25℃,80%DOD | |||||
Design Life | ≥15Years(25℃) | |||||
MECHANICAL SPECIFICATIONS | ||||||
Weight(Net/Gross)(KG) | 58.2/65kg | 96.05/102kg | 122/135kg | |||
Dimension(W/D/H)(mm) | 645*440*193 | 620*461*284 | 765*461*284 | |||
Installation Mode | On the ground | |||||
IP Grade | P40 Standard/IP54 For Customization | |||||
SECURITY AND CERTIFICATION | ||||||
Safety(Pack) | UN38.3MSDS,IEC62619(CB),CE-EMC | |||||
Safety(Cell) | UN38.3,MSDSJEC62619CEUL1973,UL2054 | |||||
Protection | BMS,Breaker | |||||
ENVIRONMENTAL SPECIFICATIONS | ||||||
Operating Temperature(℃) | Charge OC~50℃;Discharge-10℃~-50℃ | |||||
Alitude(m) | 52000 | |||||
Humidit | 595%(Non-condensing) | |||||
How does a solar energy storage system work?
A solar energy storage system typically includes components such as solar panels storage batteries, and inverters. lts operation principle is as follows:
Solar panels: Convert sunlight into direct current (DC) electricity. When sun light is received by the solar panels, they generate DC electricity and send it to the storage batteries for storage.
Storage batteries: Store the electricity generated by the solar panels. During the day, the storage batteries can store excess electricity generated by the solar panels for use at night or during cloudy weather. When electricity is needed, the storage batteries release the stored energy.
Inverter: Converts the DC electricity stored in the storage batteries into alternating current (AC) electricity for use. The inverter converts the DC electricity stored in the storage batteries into AC electricity, which is supplied to household appliances.
A solar energy storage system typically includes components such as solar panels storage batteries, and inverters. lts operation principle is as follows:
Solar panels: Convert sunlight into direct current (DC) electricity. When sun light is received by the solar panels, they generate DC electricity and send it to the storage batteries for storage.
Storage batteries: Store the electricity generated by the solar panels. During the day, the storage batteries can store excess electricity generated by the solar panels for use at night or during cloudy weather. When electricity is needed, the storage batteries release the stored energy.
Inverter: Converts the DC electricity stored in the storage batteries into alternating current (AC) electricity for use. The inverter converts the DC electricity stored in the storage batteries into AC electricity, which is supplied to household appliances.
Project cases
Recommend Products
About us
Jiangxi Xidong Export and Import Co., Ltd.
Located in Yichun City, Jiangxi Province, is known as the Lithium Capital of Asia. We insist on innovation around customer needs,offering competitive, safe, and reliable lithium battery products and solutions. We specialize in the research, development, production, and sales of lithium battery packs, serving industries such as solar energy,wind energy, and intelligent charging equipment. We are looking forward to establishing business relations with customers from all over the world.
VR
Advantages of Home Energy Storage Systems:
Energy Independence: They allow homeowners to store excess energy from solar panels or the grid, reducing reliance on external power sources.
Cost Savings: They help reduce electricity bills by storing energy during off-peak times when prices are lower and using it during peak times.
Backup Power: They provide a reliable source of backup power during outages, ensuring continuous operation of essential appliances.
Environmental Impact: They enable the use of clean, renewable energy, reducing the household's carbon footprint.
Increased Efficiency: They optimize energy usage and enhance the efficiency of home energy systems.
Grid Support: By reducing demand during peak times, they contribute to a more stable and resilient power grid.
Energy Independence: They allow homeowners to store excess energy from solar panels or the grid, reducing reliance on external power sources.
Cost Savings: They help reduce electricity bills by storing energy during off-peak times when prices are lower and using it during peak times.
Backup Power: They provide a reliable source of backup power during outages, ensuring continuous operation of essential appliances.
Environmental Impact: They enable the use of clean, renewable energy, reducing the household's carbon footprint.
Increased Efficiency: They optimize energy usage and enhance the efficiency of home energy systems.
Grid Support: By reducing demand during peak times, they contribute to a more stable and resilient power grid.
Product packaging
Certifications
FAQ
1. What is the disadvantages of LiFePO4 batteries?
- Lower energy density compared to other lithium-ion batteries.
- Higher initial cost. - Requires a Battery Management System (BMS) for safe operation.
2. Why are LiFePO4 batteries so expensive?
- Higher cost of raw materials.
- More complex manufacturing process.
- Need for an advanced Battery Management System (BMS) for safe operation.
3. What is the difference between Li ion and LiFePO4 solar batteries?
- Li-ion: Higher energy density, lighter, less stable, shorter lifespan.
- LiFePO4: Lower energy density, heavier, more stable, longer lifespan.
4. How many times can your lithium iron phosphate battery cycle?
- Typically 6000 to 8000 cycles.
5. Can you join 2 lithium batteries together?
- Yes, you can connect them in series or parallel with proper balancing and protection circuits.
- Lower energy density compared to other lithium-ion batteries.
- Higher initial cost. - Requires a Battery Management System (BMS) for safe operation.
2. Why are LiFePO4 batteries so expensive?
- Higher cost of raw materials.
- More complex manufacturing process.
- Need for an advanced Battery Management System (BMS) for safe operation.
3. What is the difference between Li ion and LiFePO4 solar batteries?
- Li-ion: Higher energy density, lighter, less stable, shorter lifespan.
- LiFePO4: Lower energy density, heavier, more stable, longer lifespan.
4. How many times can your lithium iron phosphate battery cycle?
- Typically 6000 to 8000 cycles.
5. Can you join 2 lithium batteries together?
- Yes, you can connect them in series or parallel with proper balancing and protection circuits.
