Характеристики
Engine Make
Briggs & Stratton®
Engine Model
MOD44 Commercial Series™
Cylinders
2 Cylinders V-Twin
Cutting Width (cm / inch)
112 / 44
Deck Configuration
Rear discharge and mulching blades
Height of Cut (cm)
3,8 - 11,4
Deck Construction
3,4 mm fabricated construction, full width double top deck, metal scuff guards, reinforced leading edge, overlap welded corners
Mower Spindles
Cast aluminium Ø133 mm; Ø25,4 mm shaft
Deck Lift System
Foot pedal
PTO Clutch
Warner CMS Clutch-Brake (271 Nm)
Front Suspension System
Pivoting front axle with front ride dampening shocks
Rear Suspension System
Swingarm rear wheel suspension system utilizing a pivoting transaxle cradle and large adjustable coil-over-shocks
Reactive Deck Mounting System
Rear
Drive System
Independent Hydro-Gear® ZT-3400® transaxles
Drive Axles
Ø28,6 mm drive shaft with 4-bolt wheel hub
Drive Tyres (inch)
20 x 8.00 - 10 (4 ply) Pneumatic tyre w. turf tread
Caster Tyres (inch)
11 x 4.00 - 5 (4 ply) Pneumatic tyre w. smooth tread
Speed-fwd. (km/h)
0 - 14,5
Seat
Mid-back seat with armrests (chassis mounted seat belt)
Roll-Over Protection Structure
Standard, foldable
Instrumentation
Fuel gauge, hour meter
Controls / Safety Circuit
Independent (left and right) forward & reverse levers, Seat activated engine kill, PTO clutch safety switch, neutral and parking brake safety circuit
Parking Brake
Integrated transaxle brake
Warranty (Balance of Machine) ‡
4-Years Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months)
Warranty (Coil-Over-Shocks, Suspension Related Components) ‡
5-Years (60 months) unlimited hours
Warranty (Hydro Drive Belt, Tires, Brake Pads, Hoses, Battery, Blades) ‡
90 Days
Warranty (Deck Drive Belt) ‡
1-Year (12 months) or 100 hours, whichever occurs first
Warranty (Engine) ‡
3-Year Manufacturer’s Limited Warranty
