Name: ABB расходомер
SKU: 1100002936327
Availability: InStock

16,50-18,00 $

35-53 $

10 000-35 000 $

7,50-7,70 $

3 $

5,50-6,40 $

Diameter and connection	4,6,10,15,20,25,32,40 thread connection
	(15,20,25,32,40)50,65,80,100,125,150,200 flange connection
Accuracy	±1%R,±0.5%R,±0.2%R(Customer-made)
Range	1:10, 1:15, 1:20
Instrument material	304 Stainless Steel, 316L Stainless Steel, etc
Medium temperature	-20°C——+110°C
Environment condition	Temperature:-10°C——+55°C, Relative humidity: 5%-90%, Atmospheric pressure: 86-106Kpa
Output signal	Sensor: Pulse frequency signal, Low voltage: ≤0.8V,High voltage: ≥8V
	Transmitter: Two-wire 4-20mA current signal
Power supply	Sensor: +12VDC,+24VDC(optional)
	Transmitter: +24VDC
	Site display type: instrument with 3.2V lithium battery
Signal transmission wire	STVPV3×0.3 ( three-wire), 2×0.3 (two-wire)
Transmission distance	≤1000m
Signal wire interface	Basic type: Hausmann interface, Explosion proof: Internal thread M20*1.5
Explosion class	Basic type: Non-explosion proof product, Explosion proof: ExdllBT6
Protection degree	IP65

ABB расходомер
