Product Description
OVERVIEW
In a fast changing and highly competitive TV market, operators and TV service providers must deliver access to content on all screens, anytime, anywhere, while also reducing complexity and driving efficiency across all platforms.
DMB-8804A-EC Classic H.264 HD 4 Channel IPTV Encoder supports audio and video collection by 4-Ch HD Full HD input. For Full HD input, each channel of Full HDinput supports output 4 groups IP streams with four different resolution (up to 1080p) and four different bitrates to meet different size screen and different bandwidth condition. Each group of IP stream supports kinds of main protocols output (HLS, RTMP, HTTP, RTSP, UDP), this enable Encoder to deliver H.264 IP streams by independent IP output to various servers for IPTV & OTT application. Such as Facebook Server, YouTube Server, Ustream Server, Adobe Flash Server, Wowza Media Server, Windows Media Server and some other servers based on HLS/UDP/RTSP/RTMP/HTTP/ONVIF protocols.
FEATURES
* Video Input: one channel Full HD + 3.5mm in
* Video Input: 4-Channel Full HD work simultaneously
* All protocols (HLS, RTMP, HTTP, RTSP, UDP) can be working simultaneously
* Support output up to 4 groupsTS over IP streams with 4 different resolutions and 4 different bitrates by each Full HD channel input
* Having 2*Jack(3.5mm) and 4*Full HD embedded audio input
*Support RTMP User name and Pass word for authentication of IPTV Server
* Capable of OSD settings for logo, text and Scroll Caption; Adjustable of audio gain;
* Support H.264 Baseline Profile/Main Profile/High Profile and MP3 & AAC audio compression
* Bitrate mode: CBR/VBR
* Capable of image parameter settings
* Configurable of Multi-Screen, Multi-Protocol, Low bitrate with high quality image.
* Any iOS browsers (iPhone, iPad, MacBook etc.) can have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players.
*Any terminal devices/decoders can have streams from IPTV Streaming Encoder directly by RTMP protocol with software players (such as VLC).
* Support HDCP protocol
* Support ONVIF Network Video Protocol
* Support multiple equipment display at the same time on a computer
* System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX
* Web-based management.
* Full-duplex mode 1000M
Specification
Specification | ||
* Video compression: H.264/AVC High/Main/Baseline Profile Level 4.0 * Frame rate: up to 60fps * Video input: 4*Full HD (HDCP protocol) Resolution: Main stream : 1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540,720x480, 720x404,704x576,640x480,640x360, auto Second Stream: 1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540,720x480, 720x404,704x576,640x480,640x360, auto Third Stream: 720x576,720x540,720x480,720x404,704x576,640x480, 640x300,352X288,320X240,320X180 auto. Fourth Stream: 720x576,720x540,720x480,720x404,704x576,640x480, 640x300,352X288,320X240,320X180 auto. * Bit-rate: 16kbps~12Mbps, CBR/VBR * Video pre-processing: Noise reduction, Sharpen, Filtering | ||
* Audio compression: AAC,AAC+,AAC++,MP3,MP2 * Audio input: 4*Full HD embedded + 2*3.5mm * Sampling accuracy: 24-bit * Bit Rate: 48kbps~320kbps * Sample-rate: 44.1KHz, 48KHz | ||
* Transport protocol: TS over IP output, HLS, RTSP, HTTP, UDP and RTMP protocol * For each Full HD to IP output, supporting output 4 groups TS over IP streams (for each group the HLS, HTTP, RTSP, UDP and RTMP protocol all enabled). with 4 different resolutions (up to 1080p) and 4 different bitrates to meet different size screen and different bandwidth condition. * Connector: RJ45, 1000M | ||
* Voltage: 12V DC * Consumption: less than 20W. * Operating temperature: 0~45℃(operation), -20~65℃(storage) * Dimensions: 175mm(W)*112mm(D)*60mm(H) * Weight: 0.6Kg/pc | ||
Diagram
HOT SALE
Praise From Customers
Send Inquiry
DMB-8800A-EC Family
Order Guide: MINI Series - Economic Streaming Encoder ● → Yes - → No | ||||||||||
Model Configuration | DMB-8800A-EC Classic | DMB-8800A-EC Classic | DMB-8900A-EC Classic | DMB-8804A-EC Classic | DMB-8808A-EC Classic | |||||
Video Input | HDMI | SDI | HDMI/SDI (1 of 2) | 4*HDMI | 8*HDMI | |||||
Audio Input | Embedded & Jack in | Embedded | Embedded | Embedded & 2*Jack in | Embedded | |||||
Output | IP Streaming | IP Streaming | IP Streaming | IP Streaming | IP Streaming | |||||
H.264/AVC | ● | ● | ● | ● | ● | |||||
H.265/HEVC | - | - | ● | - | - | |||||
Dolby AC3 | ● | ● | ● | ● | ● | |||||
1080P 30fps | ● | ● | ● | ● | ● | |||||
1080P 60fps | - | ● | ● | ● | ● | |||||
Preview | ● | ● | ● | ● | ● | |||||
Web&APK Control | ● | ● | ● | ● | ● | |||||
OSD | ● | ● | ● | ● | ● | |||||
Subtitle | ● | ● | ● | ● | ● | |||||
HOTSALE
DMB-8800A-EC Classic ProVideo Streaming Encoder
Input: 1*HDMI or SDI+3.5mm
Output:TS over IP(1000M)
DMB-8900A-EC Classic ProVideo Streaming Encoder
Input: 1*HDMI or SDI
Output: TS over IP(1000M)
DMB-8900N Ultra 4G/LTE Live Streaming Encoder
Input: 1*HDMI or SDI+3.5mm
Output: TS over IP(1000M)
DMB-8800BE ProVideo Streaming Decoder
Input:IP(RTSP/HTTP TS/HTTP FLV/RTMP/UDP)
Output:1*HDMI/CVBS/VGA
DMB-8808A-EC Classic ProVideo Streaming Encoder
Input: 8*Full HD+3.5mm
Output:TS over IP(1000M)
About Us
FAQ
1.What the difference between H.264 and H.265 encoder format?
Mostly, it depends on the Server you use. If your terminal decoding could support H.265 decoding, we recoomend you the one by H.265. Because compared to the H.264, H.265 encoder format able to transfer more programs in limited bandwidth.
2.Can this support HLS protocol?
Yes, it’s compatible with HLS(M3U8), HTTP/UDP/RTSP, RTMP, ONVIF, RTMP protocols.
3.Which input do you have?
It depends on the products. For this economic series, we have HD interface, SDI input only.
4. Can this stream to the Facebook, YouTube and so on. Is that compatible with the OBS Streaming Software?
Yes. our encoder could stream to the Facebook, YouTube, Twitch etc. And the OBS software uses RTMP protocol, so this encoder could compatible with the OBS.
5. How and where can I set up the device? Is by software?
You could set up the encoder by Web-management. It's very easy for operation. You can add a logo and subtitle. We also will send a User Manual with encoder. And our technical will to be of help.
6. How is the delay?
The delay of this device is about 200 ms. If you find the delay is more than that, could be caused by the internet or decoder.
7.I am a Cameraman, Which device is better for me?
If you need move the camera often, and will use it in the outdoor, we recommend you the one with WIFI, Battery and 4G/3G function.It’s super suitable for the Mobile Live Streaming Event, is that DMB-8900N Ultra. Please note, the WIFI and Battery function is banded, can’t be separated.
8.I never use this device before/I don’t know if the device suit our local market, Can I get a sample for test firstly.
Yes, even if we are doing wholesale business, We could fully understand the further cooperation is based on time and the goods’ quality. So one set of sample is totally welcomed.
9.How long will I receive my product?
All our products are in stock. It will take about 3-7 work days after we get the payment. Because before shipping, we need to all test the device.
Mostly, it depends on the Server you use. If your terminal decoding could support H.265 decoding, we recoomend you the one by H.265. Because compared to the H.264, H.265 encoder format able to transfer more programs in limited bandwidth.
2.Can this support HLS protocol?
Yes, it’s compatible with HLS(M3U8), HTTP/UDP/RTSP, RTMP, ONVIF, RTMP protocols.
3.Which input do you have?
It depends on the products. For this economic series, we have HD interface, SDI input only.
4. Can this stream to the Facebook, YouTube and so on. Is that compatible with the OBS Streaming Software?
Yes. our encoder could stream to the Facebook, YouTube, Twitch etc. And the OBS software uses RTMP protocol, so this encoder could compatible with the OBS.
5. How and where can I set up the device? Is by software?
You could set up the encoder by Web-management. It's very easy for operation. You can add a logo and subtitle. We also will send a User Manual with encoder. And our technical will to be of help.
6. How is the delay?
The delay of this device is about 200 ms. If you find the delay is more than that, could be caused by the internet or decoder.
7.I am a Cameraman, Which device is better for me?
If you need move the camera often, and will use it in the outdoor, we recommend you the one with WIFI, Battery and 4G/3G function.It’s super suitable for the Mobile Live Streaming Event, is that DMB-8900N Ultra. Please note, the WIFI and Battery function is banded, can’t be separated.
8.I never use this device before/I don’t know if the device suit our local market, Can I get a sample for test firstly.
Yes, even if we are doing wholesale business, We could fully understand the further cooperation is based on time and the goods’ quality. So one set of sample is totally welcomed.
9.How long will I receive my product?
All our products are in stock. It will take about 3-7 work days after we get the payment. Because before shipping, we need to all test the device.
Contact us
Contact Person | Bruce Chen |
E-mail | service@ digicast.cn |
Company Website | www.digicast.cn |
Whatsapp/Wechat Phone | +86-17888214818 |
Skype | 17888214818 |
