mini Horizontal axis wind turbine

Категория: Electricity Generation >>>
Поставщик: Greenergy Technology Co. Ltd

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

INSTRUCTION:

Babylon series wind turbine is traditional wind turbine, features with small& light structure, strong power making ability and cost efficiency.

The generator is one of the most reliable one in the world, it made of refined magnetic material, copper alloy, aviation aluminum alloy case and stainless steel, and it is highly efficient in power. It can generate more power than you can image. The max. Output power is more than two times of the rating power.

By yawing and brake the wind turbine protect itself from Hurricane

Babylon series wind turbine could work with off grid inverters which use battery group to store energy. Suitable for remote areas where is not available for state grid, such as remote village, mountainous areas, remote observation site, boat and TV transmission station etc.

We also design grid-tied inverter and controller for these kind wind turbines.

INSTRUCTION:

Babylon series wind turbine is traditional wind turbine, features with small& light structure, strong power making ability and cost efficiency.

By yawing and brake the wind turbine protect itself from Hurricane

We also design grid-tied inverter and controller for these kind wind turbines.

Model	AP4 (400W)	AP6(600W)	AP10(1KW)	AP20(2KW)	AP30(3KW)
Rated power(W)	400	600	1000	2000	3000
Rated voltage(V)	24	24	48	120	240
Rotor diameter(in/m)	90/2.3	102/2.6	114/2.9	130/3.3	177/4.5
Cut in wind speed	6.7mph-3m/s
Cut out wind speed	56mph-25m/s
Start-up wind speed	4.9mph-2m/s
Rated wind speed	29mph-13m/s	17.9mph-8m/s	20.2mph-9m/s	20.2mph-9m/s	22.4mph-10m/s
Survival wind speed	110mph-49m/s
Furling type	Mechanism
Rated rotating rate(r/m)	510	420	400	300	220
Generator work way	magnetic saturation
Generator material	casted iron	casted iron	casted iron	steel	steel
Blade	fiber glass,3pcs	fiber glass,3pcs	fiber glass,3pcs	fiber glass,3pcs	fiber glass,3pcs
Guy cable tower height	158 to 354 in (4 to 9m)			236 to 472in(6 to 12m)
Free stand tower height(m)	-			8m	12m
recommend battery capacity	12V150AH2pcs	12V200AH2pcs	12V200AH4pcs	12V200AH10pcs	12V200AH20pcs
Matched inverter type	sine wave
Controller function	1. PWM charging protection; 2. Stable voltage output; 3. Manual and electric barking; 4.Overvoltage protection; 5. Hybrid wind turbine and solar panel system is an optional.
