TECHNICAL SPECIFICATIONS :-

LAMINATION MACHINE :-

Machine Type

:

Lamination Machine

Maximum Web width

Power requirement

Core Inner Dia.

Maximum Reel Dia.

Unwinder for Polyester

Coating Station

Drying Tunnel

Nipping Station

Unwinder for LD

Rewinder

Pannel

Material to handle

:

:

:

:

:

:

:

:

:

:

:

:

48”(1200mm)

3 H.P. A.C. for Coating Unit

3 H.P. A.C. for Laminating unit

5 H.P. A.C. for Rewinder Unit

0.5 H.P. Pneumatic Break for Unwinder – 1

0.5 H.P. Pneumatic Break for Unwinder - 2

Web-Alliner 0.5 H.P. A.C. X 3 Nos.

3 H.P. Heaters for heater roll

3 H.P. Exhaust Blower for Exhaust

76 mm

800mm

1 No. C.I. Body (45mm thick)

Auto Tension Control – Magnetic Break Control by 5 Drive System

Shaft made from En-8 material with cones, collar nut

1 No. C.I. Body (45mm thick)

Gear box – ‘Shanthi Make’ with highly efficient bewel gears.

Cylinder shaft made from En-8 material

Ink tray system

Dr. blade system with oscillation system

Guide roll 4” dia.

Drying Tunnel length 24’

Completely Jacketed with glass wools

Divided in 3 zones

Doors at operator side for easy cleaning of rolls.

SRA Unit for Controlling the Web Edge.

1 No. C.I.Body (45mm thick)

1 No hard crome plated heater roll is provided with heater

Guide roll 4” dia.

Same as Unwinder – I

1 No. C.I.Body (45mm thick)

5 H.P. A.C. motor control by 5 Drive System

Rewinder shaft made from En-8 material with cones and Collar nut

Completed with temp indicator

Web-Alliner Controls etc.

5 Drive Pannel

Polyester, LDPE, BOPP etc.
