2022 новые тяжелые контейнерные подъемные наконечники Camlock

Описание и отзывы

Характеристики

 These container lifting lugs are supplied, and used, in sets of 4 and have a total lifting capacity of up to 56 tonne. The CLT and CLB lugs serve as flexible lashing points for the transportation of containers.
Two types are available dependant on if you want to fasten them to the top or the side of the container:
The CLB type is vertically mounted in the hole at the top of the container and is locked into place by simply turning the lug 900. This configuration allows for transportation via the use of a lifting frame in conjunction with cables, chains or slings.
The CLB model is mounted horizontally to the side of the container at either the top or the bottom fixing holes. This model has a spring loaded bolt to prevent accidental release.

For easy connection to wire rope or chain legs.
Full traceability Proof tested and certified
A 4-leg sling is also possible to use but then you need to:
Make sure the hooks and chains can move free to the intended load angles without obstruction.
it should always be used with, either a 2 or 4 point spreader beam / spreader bar.It is available as a straight and turned 45 degrees. To avoid the risk of disengagement during use, a tolerance of +/- 15 degrees from nominal should be adhered to.
We recommend that you use a spreader and lift from the bottom when the container is loaded as this is where the container is strongest.
If a two point connection spreader is used the WLL is to be reduced due to the angles.
Only lift in the bottom corners.
