DW51 P 50 пластиковый полив 2 дюйма 50 мм нормально открытый электромагнитный клапан 220 вольт

Сохранить в закладки 1600055886586:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description


Plastic 2 inch 50 mm normally open water solenoid valve irrigation


Characteristic:

1.Direct lifting diaphragm construction;
2.Open from zero bar for low pressure system use;
3.High frequency of flying lead coil.



Material:

Body-Brass,Stainless steel
Seal- NBR, EPDM or VITON
Armature Tube-Stainless Steel 304
Plunger- Stainless Steel 430F

Stop- Stainless Steel 430F
Springs- Ss304
Shading Rings- Copper



Medium:
Air, Gas, Water, Light oil, etc.
Temperature:
NBR Seal:-10℃ to 80℃

Pressure:
0-0.7 MPa
Port Size:
1/2''~ 2''
Port Thread:
G, BSP, NPT
Orifice(mm):
15~50
Voltage:
DC -6V,12V,24V   AC -12V,24V,120V,240V/60Hz'110V,22V/50Hz   Tolerance:+/-10%
Coils:
410,26VA(AC),18W(DC),IP65,100%ED




Related Products




Specifications


2W51NO Normally open, with Coil 410,DIN
Valve
Body
Port
Size
Orifice
Cv
Min
Pressure
(MPa)
Max Pressure(MPa)
Seals
Material
Body
Material
AC(22VA)
DC(17W)
2W51NO15XXX
1/2''
15
4.8
0.0
0.6
0.6
NBR
PA66
(Nylon)
2W51NO20XXX
3/4''
20
7.6
0.0
0.6
0.6
2W51NO25XXX
1''
25
12
0.0
0.6
0.6
2W51NO32XXX
1 1/4"
32
22
0.0
0.4
0.4
Or EPDM, VITON
2W51NO40XXX
1 1/2"
40
30
0.0
0.4
0.4
2W51NO50XXX
2"
50
48
0.0
0.4
0.4


\t\t\t\t\t\t\t\t\tCertifications \t\t\t\t\t\t\t




Our Company










Each Darhor Valve pass 10 testings to ensure high quality!

Valve testing:                                                                       Coil testing:

high pressure test    low pressure test

leak detection   water hammer test    lifecycle test

            resistance test     current test

            power test       temperature test      noise test



Packing & Delivery


Shockproof Bag to protect valve


Strong Cartons

1.English neutral packaging
2.with Darhor logo
3.with your logo (Charged)

membrane outside protect rain

Package more than 40kgs,use
Fumigated wooden case or pallet.



We will compensate to the damage!pls contact within 3 days when you receive.
