Product Description
1" DN25 12V 24V CF8 On/Off motor shutoff 3 way electric valve for Hot and cold water meter
Pls confirm the two details when you order them.
| No. | Item | Need to be confirmed |
| 1 | Wiring diagram | CR201 CR303 CR501 or CR703 |
| 2 | Voltage | DC12V or DC24V |
| 3 | Valve thread | BSP or NPT female thread |
| 4 | Flow direction | L port or T port |
Flow direction
Wiring diagram
CR201 wiring diagram
RD connect with positive, the BK connect with negative, the valve closed, the actuator automatically power off after in place , the valve remains fully closed position .
BK connect with positive, the RD connect with negative, the valve open, the actuator automatically power off after in place, the valve remains fully open position .
Suitable Working Voltage: DC12V, DC24V
Exceeding the working voltage is forbidden
CR501 wiring diagram ( with feedback signal)
RD connect with positive, the BK connect with negative,the valve closed, the actuator automatically power off after in place .
BK connect with positive, the RD connect with negative,the valve open, the actuator automatically power off after in place .
GR & WT are connect when the valve open fully, YW & WT are connect when the valve closed fully.
Suitable Working Voltage: DC12V, DC24V
Exceeding the working voltage is forbidden!
CR303 wiring diagram
RD& GR connect with positive, the BK connect with negative.
SW CLOSED, the valve OPEN, the actuator automatically power off after in place
SW OPEN, the valve CLOSED, the actuator automatically power off after in place.
Suitable Working Voltage: DC12V, DC24V
Exceeding the working voltage is forbidden
CR703 wiring diagram ( with feedback signal)
RD& GR connect with positive, the BK connect with negative.
SW CLOSED, the valve OPEN, the actuator automatically power off after in place
SW OPEN, the valve CLOSED, the actuator automatically power off after in place.
BL & GY connect with the valve’s fully open signal wiring
YW & WT connect with the valve’s fully closed signal wiring.
Suitable Working Voltage: DC12V, DC24V
Exceeding the working voltage is forbidden
