Configure Advantages

asphalt wastes recycling 100%  mobile bitumen mixing plant asphalt mixer for road repair pavement repatch,bitumen wastes recycling 100% is called one mobile asphalt mixing pant cold asphalt mixer for road repair pavement repatch800Bpj

100% cold wastes bitumen recycling asphalt mixing pant for pavement repair

Our domestic unique dual-mixing comprehensive road repair vehicle can recycle and reuse old asphalt by mixing, and can also produce new asphalt mixture materials, dual-use- mode adopt double-tanks simultaneous regeneration of old asphalt mixture, or new asphalt mixture production simultaneously in double-tanks mixing, production capacity :Two tons at a time, or one tons at a time according to the workload, in addition, it is equipped with one 1000L asphalt heating mixing tank, the maximum load mixing capacity of this equipment can actually reach 2.4~2.5 tons per batch, a single tank can Mix up to 1.2 tons, it is recommended that single-tank to mix &stir 1 ton is the most suitable working mode in the case of high-efficiency and high-yield long-term operations. There's One tank can give a regeneration of old asphalt simultaneously that the other tank can mix&stir new asphalt materials , or double tanks can simultaneously mix old asphalt Regeneration or produce new asphalt mixture, we are the only domestic double-tanks asphalt mixer manufacturer, with unique design advantages, high efficiency and high production mode, and more favored by customers_20200609104604_.jpg



















































































































































Technical Date



Heating system



Mixer tank burner power



310KW



Asphalts tank burner power



60KW



Hydraulic system



System pressure



16Mpa



Rated total flow



140L/Min



Dedusting system



Dedust mode



(Cyclone+water )dust remove



Dedust dynamics



Hydraulic engine



Dedust ability



1100m3/h



Loading system



Loading type



Single hydraulic cylinder lift chain climb-type



Hopper capacity



300KG



Emulsified asphalt spraying system



Asphalt tank capacity



100-200L



Spraying speed



10-60L/Min



Highpressure air self-clean pipeline



0.7Mpa



Asphalts regeneration Mixer system



Single regeneration capacity



2000kg/time



Regeneration Ability



12-16T/h



Fuel consumption



4-6L /T



Mixing mode



Double hydraulic driven vertical forced mixing



Discharge mode



simultaneously discharge or seperately



Asphalts discharge Temp.



120-180 ℃



Heating mode



Burner heating or hot air circulation heating



Asphalts spraying system



Asphalts tank capacity



500-1000L



Asphalt measurement method



Continuous unlimited metering



Temp. control Range



120-180 ℃



Electric heating hose



6m/ full heating/360o rotate



Spraying speed



80-100L/min



Asphalts heating time



1000L/2-3h



The heating wall system






Heating mode



Fuel gas infrared heating+Blue flame thermal radiation technology



Heating area



2000*1000mm (1/4 area, can work along)



Reversal mode



Hydraulic driving,90o reversion



lateral movement



To move Left or right of 35mm



Height movement



100mm



Application



Road pothole repair/Road surface spraying/ crack-sealing



Equipment



 Equipped with hydraulic crane,  construction equipment  small road roller, etc






Function+Repair step


3). It adopts vertical forced mixing to mix asphalt concrete.4). The whole vehicle is driven by full hydraulic pressure. The main hydraulic components are American Eaton products, which are easy to operate and safe to work.5)Asphalt pipes and asphalt pumps are built-in and are free of cleaning after use.

-69996896_2

6). With asphalt measuring device, according to the need, measure the amount of asphalt per kettle to ensure the oil-stone ratio of the mixture. 7). The asphalt tank is equipped with intelligent automatic temperature control device and liquid level control alarm device to ensure the temperature of asphalt and the loading of asphalt.8). The mixing bin is equipped with an infrared scanner to effectively control the temperature of mixing and discharging. 9). Adopt the tail-feed design to reduce the road surface during construction and avoid traffic jams 10). The side design is used for discharging, and the discharging can directly go to the pit, which reduces labor intensity and improveswork efficiency. 66663_cara.jpg13.

1). Select Dongfeng truck chassis, power steering, air conditioning, air conditioning, suitable for all kinds of conditions.2). Adopt cyclone dust removal device, smokeless and dust free, energy saving and environmental protection.P90614-164037_.jpg



infrared heat wall


 In addition, the equipment can be equipped with the world's leading gas infrared heating-wall, which can be controlled dividedly , the construction is more flexible, and it is effective against vibration and wind resistance. The construction takes only 10-15 minutes.800asphalt recyclingroad repatch process.IMG20200220104451_12333





Company profile


Founded in 1998, .Now Youyi machinery company is located in the NO.11 industrial park,National High-Tech Industrial Zone of Jining city , Shandong ,China. it integrates the manufacture,design, research&development and sales in one and has been focusing on road maintenance products fields for more than 20 years. Our company actively adheres to the concept of environmental protection innovation and In line with the global ecological environmental protection strategy, the multi-function comprehensive road maintenance equipment developed is not only energy efficient but also environmentally friendly and sold well in such countries and regions as Australia, Malaysia, Indonesia, South Africa, Turkey and other Southeast Asian, Middle Eastern, European and American countries.Now our company provides three main series of more than 50 kinds of products, such as road comprehensive maintenance vehicle, road-crack joint equipment and small road construction machinery etc. It has obtained more than 32 national patents, passed SGS international certification, and obtained the quality manage system certification of ISO9001, ISO14001, QHSAS18001 and so on. Besides, we have got many domestic honorary titles such like domestically certified AAA-level star enterprises. 32patengs
