Leabon корма для животных машины длительный срок службы мельница кормушка домашней птицы лепешка делая линию
- Категория: >>>
- Поставщик: Zhengzhou Leabon Machinery Equipment Co. Ltd.
Сохранить в закладки 1600094887007:
Описание и отзывы
Характеристики
Product Description
Item | Feed Pellet Production Line |
Suitable Raw Material | corn, maize, grass, grains, molasses, wheat, beans etc. |
Feed application | poultry, livestock and aqua animals like: cattle, pig, sheep, shrimp, fish, pet etc. |
Technical Parameters | - Capacity: 0.5t/h-2t/h - Dimensions: Designed according to specific requirements. |
Features | - Highly efficient one step gear transmission drive ensures maximum utilization ratio of energy. - Full stainless steel feeder; Variable-pitch anti-arch structure; Imported frequency converter control. - Stainless steel conditioner extends the conditioning and cooking time. Axial steam spraying port, improving feed cooking efficiency. - High precision driving main gear and pinion shaft adopt the carbonizing quenching and hard tooth surface grinding technology, resulting in smooth driving, low noise and long service life. |
(1)crushing process
The task of this section is to crush the clean materials we got in the last section into powder(less than 3mm),and then deliver the powder to the next section.
(2)mixing process
The task of this section is:
A. evenly mix different materials into complete powder feed. B. According to the certain operation order between the bin for the mixer, the mixer and the buffer bin,to ensure the continuous operation.
Model | HJJ50 | HJJ71 | HJJ80 | HJJ100 |
Effective volume (m³) | 0.2 | 0.5 | 1.0 | 2.0 |
Each batch mixing Amount(kg) | 120 | 250 | 500 | 1000 |
Mixing uniformity (cv%) | ≤6 | ≤6 | ≤6 | ≤6 |
Each batch mixing time(s) | 3-5 | 3-5 | 3-5 | 3-5 |
Spindle speed(r/min) | 54 | 42 | 34 | 34 |
Power(kw) | 2.2 | 4 | 7.5 | 18.5 |
Weight(kg) | 288 | 478 | 766 | 1600 |
Out-size(m) | 1.55*0.9*.1.1 | 2*1.22*1.15 | 2.6.1.1*1.4 | 3.1*1.8*1.61 |
(3) pelleting process
The task of this section is to pellet the powder feed to required sizes.
Parameter/Model | CM -15A | CM-20A | CM-25A | ||
Output(kg/h) | 100-200 | 500-700 | 1000-1200 | ||
Power (kw) | 3 | 11 | 22 | ||
Revolving Speed of ring die (r/min) | 420 | 306 | 306 | ||
Inside diameter of ring die(mm) | 150 | 200 | 250 | ||
Pellet diameter(mm) | Φ1.5、Φ2、Φ2.5、Φ3、Φ3.5、Φ4、Φ5、Φ6、Φ8 | ||||
Dimension(m) | 0.75*0.45*0.8 | 1.1*1.15*1.25 | 1.1*1.15.1.25 | ||
Weight(kg) | 175 | 500 | 625 | ||
Parameter/Model | CM-20B | CM-25B | CM-30B | ||
Output(kg/h) | 500-700 | 1000-1500 | 1500-2000 | ||
Power (kw) | 11 | 22 | 30 | ||
Feeding motor(kw) | 0.75 | 0.75 | 0.75 | ||
Revolving Speed of ring die (r/min) | 306 | 306 | 330 | ||
Inside diameter of ring die(mm) | 200 | 250 | 304 | ||
Pellet diameter(mm) | Φ1.5、Φ2、Φ2.5、Φ3、Φ3.5、Φ4、Φ5、Φ6、Φ8 | ||||
Dimension(m) | 1.1*1.5*1.52 | 1.1*1.15*1.25 | 1.35*1.3*1.6 | ||
Model | SKLN0.6 | SKLN1.0 | SKLN1.5 | SKLN4 | SKLN8 | SKLN12 | |||||
Volume(m³) | 0.6 | 1 | 1.5 | 4 | 8 | 12 | |||||
Capacity(t/h) | 1 | 2 | 3 | 10 | 20 | 30 | |||||
Cooling time(min) | 6-10mins | ||||||||||
Temperature after cooling(℃) | Not higher than +3~5℃ | ||||||||||
Air volume(m³/min) | 34 | ||||||||||
Power(kw) | / | 0.75 | 0.75 | 1.5 | 1.5 | 1.5 | |||||
Airlock(kw) | / | 0.37 | 0.37 | 0.55 | 0.55 | 0.55 | |||||
Model | DB-1A | DB-5A | DB-25A | DB-50A | DB-100A | ||||
Packing Range | 0.2-1kg | 1-5kg | 2.5-25kg | 5-50kg | 10-100kg | ||||
Packing Error | 0.2%F.S | 0.2%F.S | 0.1 %F.S | 0.1 %F.S | 0.1 %F.S | ||||
Division Value | 2g | 5g | 10g | 20g | 20g | ||||
Packing Speed | 300-500 bags/h | 300-420 bags/h | ≥300 bags/h | ||||||
Power | AC 220V 50Hz | ||||||||
Air Supply | 0.4-0.8 MPa | ||||||||
Machine Dimension | 1725x620x710 (mm) | 1890x620x710 (mm) | 2450x650x715 (mm) | 2560x650x715 (mm) | 2960x730x775 (mm) | ||||
Actuator | pneumatics | ||||||||
Accuracy Class | X(0.2) X(0.1) | ||||||||
Final Pellet
Packing&Shipping
Packing Details: Internation standard packing in wood case.
Shipping Time: Shipped in 15-20 days after payment.
Shipping Time: Shipped in 15-20 days after payment.
Related Products
After Sales Service
1) The professional and timely 24 hours after-sale service.
2) The relative manual and video of the machine installation and instruction will be provided for you.
3) ODM&OEM Provided.
4) The engineer is available to install and training for oversea projects.
2) The relative manual and video of the machine installation and instruction will be provided for you.
3) ODM&OEM Provided.
4) The engineer is available to install and training for oversea projects.
Company Introduction
Zhengzhou Leabon Feed Machinery Co., Ltd. is a professional and advanced supplier which mainly supply feed equipments like feed crusher,mixer,pellet machine,granule crumbler,feed pellet cooler, packing and entire feed pellet production line.With rich experience for many years.
FAQ
Q: What the main function about this machine?
A: This machine is the main machine of making granular fodder,such as animal feed,poultry feed.
Q: What industry is this machine suitable for?
A: The machine can use for livestock farm,feed mill,checmical industry,fertilizer industry and sugar industry.
Q:I know very little about this machine, How should I make a choose?
A:please tell us your specific requirement, we will offer the most appropriate model for you,you can contact us at any time.
Q:Do you have a warranty?
A:Yes,we have one year warranty for our products.
Q:If the machine has a little mistake when produce and can not solve,what should i do?
A：Please contact us immediately,by email,or telephone,our worker will give you the solution.
A: This machine is the main machine of making granular fodder,such as animal feed,poultry feed.
Q: What industry is this machine suitable for?
A: The machine can use for livestock farm,feed mill,checmical industry,fertilizer industry and sugar industry.
Q:I know very little about this machine, How should I make a choose?
A:please tell us your specific requirement, we will offer the most appropriate model for you,you can contact us at any time.
Q:Do you have a warranty?
A:Yes,we have one year warranty for our products.
Q:If the machine has a little mistake when produce and can not solve,what should i do?
A：Please contact us immediately,by email,or telephone,our worker will give you the solution.
