Mining PFL1500 Big Iron Ore Plant Stone Crusher Price Car Crusher Machine Vertical Combined Pebble Glass to Sand Crusher
Product Description
Product Name | Glass to Sand Crusher |
Suitable for | Glass, Waste, Pebble,rock( the limestone, granite, basalt, aluminum, andesite,etc.) |
Color | Customizable |
The Vertical Compound Glass to Sand Crusher is a new generation of high-efficiency crusher developed by Henan Hongke heavy machinery co.,ltd. according to the same kind of crusher technology at home and abroad and optimized design of main technical parameters.
The structure of thawing hammer crusher and counterattack crusher is especially suitable for crushing brittle materials with medium hardness and low water content in building materials, mining, chemical industry, metallurgy, cement, coal and other industries.
The structure of thawing hammer crusher and counterattack crusher is especially suitable for crushing brittle materials with medium hardness and low water content in building materials, mining, chemical industry, metallurgy, cement, coal and other industries.
Vertical compound liming stone crusher is a crushing machine for crushing material with a maximum size of 600-1800 mm to 25 mm or less.
Working Principle of Vertical Compound Glass to Sand Crusher
The device is driven by a motor rotor in the breaking chamber high-speed rotation.
Material from the upper feed into the machine is crushed by the impact of high-speed hammer, shear, grinding action.In the lower part of the rotor, a sieve plate is arranged.
The particles smaller than the size of the sieve hole in the comminuted material are discharged through the sieve plate,
and the coarse particle resistance larger than the size of the sieve hole is left on the sieve plate to continue to be hit and ground by the hammer.
Finally, it is expelled from the machine by the sieve plate.
Material from the upper feed into the machine is crushed by the impact of high-speed hammer, shear, grinding action.In the lower part of the rotor, a sieve plate is arranged.
The particles smaller than the size of the sieve hole in the comminuted material are discharged through the sieve plate,
and the coarse particle resistance larger than the size of the sieve hole is left on the sieve plate to continue to be hit and ground by the hammer.
Finally, it is expelled from the machine by the sieve plate.
(1) The structure is simple and reasonable, and the running cost is low.
(2) High crushing rate and energy saving.
(3) It has fine crushing and rough grinding function.
(4) It has little effect on the moisture content of the material, and the moisture content can reach about 8%.
(5) less than 75 dB (db) noise and less dust pollution.
(6) It is suitable for crushing medium hard, special hard material.
(7) The products are cubes with high density and minimal iron pollution.
(2) High crushing rate and energy saving.
(3) It has fine crushing and rough grinding function.
(4) It has little effect on the moisture content of the material, and the moisture content can reach about 8%.
(5) less than 75 dB (db) noise and less dust pollution.
(6) It is suitable for crushing medium hard, special hard material.
(7) The products are cubes with high density and minimal iron pollution.
Detailed Images
Size Information
Type | Feeding size(mm) | Discharging size (mm) | Capacity(t/h) | Spindle speed(r/min) | Motor (kw) |
PFL-500 | <100 | <3-5 60-90% | 1-5 | 1000 | 4 |
PFL-800 | <100 | <3-5 60-90% | 15-20 | 934 | 22 |
PFL-1000 | <120 | <3-5 60-90% | 35-50 | 760 | 45 |
PFL-1250 | <150 | <3-5 60-90% | 50-80 | 530 | 75 |
PFL-1500 | <180 | <3-5 60-90% | 70-100 | 495 | 132 |
PFL-1750 | <200 | <3-5 60-90% | 130-160 | 424 | 160 |
PFL-2000 | <220 | <3-5 60-90% | 150-190 | 370 | 185 |
Working Sites
Delivery and Packing
Company Introduction
Henan Hongke Heavy Machinery Co., Ltd. is located in Henan Province which is the cultural base of the central area of China. We are a mining machinery manufacturing enterprise that integrates scientific research, production and marketing.
We are a high-tech enterprise that specializes in the research and production of rotary kilns, dryers, crushers and so on, such as new type of lime rotary kiln, ceramsite kiln, zinc oxide rotary kiln, sludge rotary kiln, chemical rotary kiln, metallurgical
rotary kiln, Raymond mill, ultra-fine mill, large and medium dryer, ball mill, sand mill,stone production line, mineral processing equipment and so on.
From the design, production, installation and debugging, we provide you the entire tracking service.We adhere to the aim of high quality to survive, good credibility to make development, and sincerely look forward to cooperating with you!
We are a high-tech enterprise that specializes in the research and production of rotary kilns, dryers, crushers and so on, such as new type of lime rotary kiln, ceramsite kiln, zinc oxide rotary kiln, sludge rotary kiln, chemical rotary kiln, metallurgical
rotary kiln, Raymond mill, ultra-fine mill, large and medium dryer, ball mill, sand mill,stone production line, mineral processing equipment and so on.
From the design, production, installation and debugging, we provide you the entire tracking service.We adhere to the aim of high quality to survive, good credibility to make development, and sincerely look forward to cooperating with you!
Related Products
FAQ
1. What is the minium order quantity?
One set.
2.How long is the warranty period?
One year. Wearing parts are excluded.
3. What is the after-service of your company?
We can provide the customers foudation drawing, installation service, work training as well as other service according to the customer's requirements.
4.How long is the delivery time?
About 15 days after we receive the payment.
5. What are the payment terms?
T/T, L/C are the best, it can be adjustable according to different situations.
One set.
2.How long is the warranty period?
One year. Wearing parts are excluded.
3. What is the after-service of your company?
We can provide the customers foudation drawing, installation service, work training as well as other service according to the customer's requirements.
4.How long is the delivery time?
About 15 days after we receive the payment.
5. What are the payment terms?
T/T, L/C are the best, it can be adjustable according to different situations.
Kindly Note:
1. Please pay attention to the capacity. It's what you must take into consideration in choosing a suitable machine.
2. Please Inform us the follow figures:
1). feeding material
2). Feeding material MAX. Size (mm)
3). Final mesh size (mm)
4). Capacity (t/h)
Upon we got your message we shall give you our favorable offer in short time.
1. Please pay attention to the capacity. It's what you must take into consideration in choosing a suitable machine.
2. Please Inform us the follow figures:
1). feeding material
2). Feeding material MAX. Size (mm)
3). Final mesh size (mm)
4). Capacity (t/h)
Upon we got your message we shall give you our favorable offer in short time.
