ITEMS                  Parameter   Remarks
Double side & Multi-layer
Number of Layers 1-20 layers
Board Materials FR4,CME3,CME1,5G
PCB Size (Min- Max) 50x80mm  to 1000mm×600mm ( 39.37"x23.6")
innerlayer line width/space(min)   4mil/4mil(100um/100um)
Finish Plating /Surface Finishes   HASL ,OSP,ENIG,HASL,gold finger,Au Panel,OSP,ENIG
innerlayer pad (min) 5mil(0.13mm)Pad annular
Core thickness (min) 8mli(0.2mm)
Finisher Copper Inner Layers 1/2oz(17um)a-No Cu Clad
Finished Copper Outer Layers 1/2oz(17um)
Final PCB Thickness (tolerance %)  0.5-4.0mm
Final PCB Thickness (tolerance %)Thickness<1.0mm
1.0mm≤Thickness&lt;2.0mm
Thickness≥2.0mm
inner layer process   Brown Oxide
Minimum Conductor Space ±3mil(±76um)
Minimum Drill Hole Size      0.25mm
min diameter of finished hole     0.2mm
Hole position accuracy      ±2mil(±50um)
Drilled slot tolerance       ±3mil(±75um)
PTH tolerance       ±2mil(±50um)
NPTH tolerance      ±1mil(±25um)
maxA.R.Of PTH     08:01
PTH hole copper thickness     0.4-2mil(10-50um)
image to image tolerance     ±3mil(0.075mm)
outer layer line width/space(min)    3mil/3mil(75um/75um)  _02.jpg








Solder Mask Thickness line end 0.4-1.2mil(10-30um)
line Corner ≥0.2mil(5um)
on Substrate ≤Finished Cu
 thickness+1.2mm≤Finished Cu
thickness+30um)≤+1.2mil≤+30um)
min solder mask dam     4.0mil(100um)
impedance control and tolerance      50Ω±10%
warp and twist     ≤0.5%
Delivery time1-2 layers 10-12day
4-20 layers 12-20days
PackageGeneral export packaging




technological













About us







Certifications


-1





FAQ


Q:Are you manufacturer or trading company?


A: We are Manufacturer located in Jiangxi Ganzhou China. Specialized in manufacturing double-panel and multi-board PCB for over 18 years


Q:How long is your delivery time?


A:Samples need 3-5 working days,Mass production need 7-10 working days.


Q:Do you provide samples? Is it free or extra?


A: Yes,we offer the sample for free if we have it in stock.But need you pay the express fee.


Q: What is your payment terms?


A: Payment term is full payment if an trial order. And bulk order is 50% deposit and balance50% before delivery.


Q: What is your payment ways?


A: TT /Western union/ Paypal/Credit card etc.


Q:What express can we choose?


A:FedEx, UPS, DHL,TNT etc.


Q: What is you MOQ?


A: Our MOQ is 5 PANEL.


Q:Which files will need for produce PCB?


A: All pcb boards are OEM design,Send us PCB design(gerber,DXP,99SE file all ok for us)


Q:Is safty for my PCB design for manufacturing?


A: All customer's copyright will never manufacture PCB board for someone else with your files unless we receive written.
