Многофункциональная домашняя комбинированная машина для сверления бусин KYC280V

Многофункциональная домашняя комбинированная машина для сверления бусин KYC280V

Категория: >>>
Поставщик: Yangzhou Kaiyun Machinery Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

Specification
Model No.	KYC280V
Distance between centers	700mm
Swing over bed	280mm
Swing over cross slide	165mm
Width of bed	180mm
Taper of spindle bore	MT4
Spindle bore	26mm
Range of spindle speeds	50-2000rpm
Range of longitudinal feed	0.07-0.20mm/r
Range of inch threads	8-56T.P.I
Range of metric threads	0.4-3.5mm
Travel of top slide	70mm
Travel of cross slide	140mm
Tailstock quill travel	70mm
Taper of tailstock quill	MT2
Motor	1.1kw
Drilling & Milling
Taper of spindle bore	MT2
Spindle stroke	50mm
Range of spindle speeds	50-2250rpm
Max.distance spindle to table	375mm
Max.distance spindle column	185mm
Motor	600W
Packing size	14007801070mm
Net weight	230kg

Standard accessories
Splash guard	1 pc
Chip tray	1 pc
Drawbar	1 pc
Arbor	1 pc
Toolbox & tools	1 set

Optional accessories
4-jaw chuck	1 set
Follow rest	1 pc
Steady rest	1 pc
Face plate	1 pc
ER25 collet chuck	1 set
Digital rules	1 pc
Turning tools	1 pc
Stand	1 set
Leadscrew cover	1 set

Features

1.Most popular,belt driving hobby lathe.
2.V-way bed is hardened and precision ground.
3.Super width bedway gets greater capacity.
4.Spindle is supported by precision tapered roller bearing.
5.Automatic longitudinal feed allows threading.
6.T-s lotted cross slide.
7.Adjustable gibs for slideways.
8.Top design of gearbox gets large function.
9.Right/Left hand threads cutting is available.
10.Tailstock may be offset for turning tapers with two lead screws.
11.Forward/Reverse hand operation with zero.
12.Mill head can be tilt ±90°.
13.Emergency stop button and low tension release.

Packing & Delivery

Warehouse to film

Related Products

Combination Machine

KY500/KY800

KY400

Our Company

Since establishing, after years of effort, we, which is Kaiyun Machinery have grown into a professional supplier of Metalworking and woodworking machinery in China, with more than 50 domestic qualified factories as our long-term and OEM partners. Outstanding technical engineers & strict inspector ensure us turn out high quality products because they all know this is the absolutely vital that the quality is the basic of products. Our all products are exported to the worldwide markets, especially in America and Europe market.

Our Service

You can enjoy the best after service when you purchase our any product. Our technician takes serious to the every quality information feedback of our products each time, and would reply it as soon as possible. We will keep trying our best to guarantee your satisfaction, and to assure the product we send to you will meet the high quality and durable standards. If you are interested in our products or have special requirements, pls feel free to contact us without delay. Then we, Sale Dept. will give you a satisfying reply within 24 hours!
