Низкая цена универсальный бытовой токарный станок для металлообработки (KY1340D/KY1440D)

Низкая цена универсальный бытовой токарный станок для металлообработки (KY1340D/KY1440D)

Категория: >>>
Поставщик: Yangzhou Kaiyun Machinery Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

Specification
MODEL	KY1330D/KY1340D	KY1430D/KY1440D
Swing Over Bed	330mm	360mm
Swing Over Cross Slide	198mm	212mm
Swing in Gap Diameter	476mm	491mm
Swing in Length	210mm	210mm
Center Height	166mm
Admits Between	750mm/1000mm
Bed Width	187mm
Bed Length	1248mm/1655mm	1363mm/1655mm
Bed Height	290mm
Spindle Bore	38mm
Spindle Nose	D1-4or A2-4
Taper in Nose	MT5
Taper in Sleeve	MT3
Speeds Number	8
Speed Range	70-2000R. P. M
Cross Slide Width	118mm
Cross Slide Travel	160mm
Compound Rest Width	76mm
Compound Rest Travel	68mm
Lead Screw Diameter	22mm
Lead Screw Thread	8 T. P. I
Feed Rod Diameter	19mm
Cutting Tool Max. Section	16mmx16mm
Threads Imperial Pitches	36 Nos. 8-112 T. P. I
Threads Metric Pitches	28 Nos. 0.2-5mm pitch
Thread Diametral Pitches	36 Nos. 8-112 D. P.
Threads Module Pitches	22 Nos. 0.2-3M. P.
Longitudial Feed Imperial	36 Nos. 0.0019-0.0273"/Rev.
Longitudia Feed Metric	36 Nos. 0.050-0.696mm/Rev.
Cross Feeds Imperial	36 Nos. 0.0006-0.0094"/Rev.
Cross Feeds Metric	36 Nos. 0.013-0.188mm/Rev.
Quill Diameter	32mm
Quill Travel	100mm
Quill Taper	MT3
Main Motor	2HP, 3HP or 2HP, 1HP

Standard Accessories
4-jaw chuck	1 pc
Face plate	1 set
Steady rest	1 set
Follow rest	1 set
Stand	1 set
Toolbox&tools	1 set
Micro carriage stop	1 set
Working lamp	1 pc
Cooling system	1 set
Foot brake system	1 set

Optional Accessories
Quick change tool post	1 set
Turning tools	1 set
Taper turning attachment	1 set
Digital readout	1 set
Lead screw cover	1 set

Features
1.Widely useful,heavy duty bench lathe.
2.V-way bed is hardened and precision ground.
3.D1-4 spindle is supported by high quality tapered roller bearing.
4.Hardened,precision ground gears in headstock.
5.Gap bed section provided for larger diameter work.
6.Gearbox has large feed and threading functions.
7.Carriage mounted spindle control lever.
8.Adjustable gibs for slideways.
9.Automatic feed and threading are fully inter locked.
10.Independent leadscrew and feed rod.
11.Tailstock may be offset for turning tapers,
12.Equipped wity emergency stop button.
