Клей биаксиально-ориентированной пластиковой печатью фирменная упаковочная лента пропиточная машина
11 000,00 $ - 13 500,00 $
Сохранить в закладки 1600118083722:
Production capacity | 2000 ~ 7000 bottles / hour |
Applicable bottles | round plastic bottle or glass bottle |
Labeling accuracy | ± 0.5mm |
Label Specifications | Length 10 ~ 80mm wide 10 ~ 80mm |
Label roll specifications | diameter 350mm diameter 76mm |
Label gap | ≥ 3mm |
Air pressure | ≥ 0.4MPa |
Power | 220V 50Hz |
Power | 1.5Kw |
Dimensions | 2800 × 1500 × 1400 |
No. | Name | Model or Material | Supplier |
1 | PLC | DVP14SS11T2 | Taiwan Delta |
2 | touch screen | DOP-B05S100 | Taiwan Delta |
3 | Measuring bottle sensor | Japan Keith | |
4 | standard test sensor | Germany LEUZE | |
5 | bidder servo motor | 85BYGH4C | Taiwan Delta |
6 | Pneumatic Solenoid Valve | Japan SMC | |
7 | switching power supply | 1K2 | Taiwan |
8 | gear reduction motor | 60W | V. T. V |
9 | printer | NY818 | ZHANGZHOU NANYUN packaging |
10 | other electrical | components | CHINT technology |
11 | bottle conveyor belt | components | NANTONG BOLANG |
12 | Labeling System | components | NANTONG BOLANG |
13 | transmission mechanism | components | NANTONG BOLANG |
14 | rack, table | assembly (A3) | NANTONG BOLANG |
15 | side panels, panel | components (304 #) | NANTONG BOLANG |
